5. Connecting and Powering the Unit

WARNING: All connections between the Evo DAC 3 and other equipment must be
made when all units are turned off and completely powered down or unplugged.
Failing to do so may cause damage to the Evo DAC 3 and/or other units.
Please refer to chapter 3, "Back Panel".
Connect the digital sources (CD/SACD/DVD player, satellite receiver, DAB receiver) to the
inputs (Figure 2, 10-11). The Bluetooth
Connect your streamer or any other I
2, 12).
Connect your computer to the Evo DAC 3 USB input (Figure 2, 13).
Connect either Evo DAC 3 balanced or single-ended outputs to a pair of inputs on an
integrated amplifier or preamplifier (Figure 2, 8-9).
Connect the plug from the stock wall wart or from the Evo Supply 3 to the Evo DAC 3 power
input (Figure 2, 14).
Connect the wall wart or the Evo Supply 3 to a mains outlet. The former will automatically
accept any voltage from 90V
Switch the Evo DAC 3 on by pushing the left front panel button (Figure 1, 2). If you're using
the Evo Supply 3, you have to activate the output used to power the Evo DAC 3 first.
NOTE: as the Evo DAC 3 is provided with a volume control, it is possible to use it as
a preamplifier. In this case, it is a good habit to switch the power amplifier on after
switching the Evo DAC 3 on, and to switch the power amplifier off before switching
the Evo DAC 3 off.
NOTE: it is possible to use a dedicated low noise power supply in place of the wall
wart, to increase the sonic performance Manunta by M2Tech provides a device for
this purpose, the Evo Supply 3. M2Tech's Van Der Graaf M
the user opt for use of power supply not provided by Manunta by M2Tech or
M2Tech, we reserve the right to void the Evo DAC 3 warranty.
® connection will be done after powering the unit.
2 S-provided source to the Evo DAC 3 I
to 265V .
AC AC
15
MANUNTA
BY M2Tech
www.manunta-audio.com
2 S input (Figure
II can also be used. Should
k
