5. Connecting and Powering the Unit

WARNING: All connections between the HIFACE EVO TWO
be made when all units are turned off and completely powered down or unplugged.
Failing to do so may cause damage to the HIFACE EVO TWO
Please refer to chapter 3, "Back Panel".
Connect the HIFACE EVO TWO to a computer with a 2.0 A-B USB cable connected to the
USB port (Fig. 2,10). We recommend the cable be no longer than 3m.
If you also own the EVO CLOCK TWO , connect its master clock output to the HIFACE EVO
TWO external clock input (Fig. 2, 9) with a 75 Ohms BNC-terminated cable (not in stock). It
is also possible to use other clock generators, whereas their output is able to drive 75
Ohms matched lines.
If the EVO CLOCK TWO is used, connect its clock info optical input to the HIFACE EVO TWO
clock info output (Fig. 2, 11) using a Toslink™ fibre interconnect (not in stock) to make the
EVO CLOCK TWO clock switching automatic.
Connect one or more digital audio devices (DAC's, A/V receivers digital inputs, digital
mixers) to the HIFACE EVO TWO outputs (Fig. 2, 3,4,6 and 7) using the appropriate digital
interconnects (not in stock).
Connect the output of a digital audio device which signal should be acquired (e.g. a CD
player) to the HIFACE EVO TWO S/PDIF input (Fig. 2, 5).
Connect the stock +9V wall wart or one of the EVO SUPPLY TWO outputs to the supply input
of the HIFACE EVO TWO (Fig. 2, 8). Please note the HIFACE EVO TWO may also be powered
by the USB bus 5V supply. This happens every time that the device is connected to an
USB bus and no power supply is connected to its supply input. Obviously, in such a
scenario its performance will be sub-optimal.
WARNING: the maximum voltage allowed by the HIFACE EVO TWO
connector is 15V. Whenever a power supply delivering more than 15V is used, the
HIFACE EVO TWO HIFACE EVO TWO may be damaged. Should this be the case, the warranty is void and HIFACE EVO TWO HIFACE EVO TWO
servicing or replacement of the faulty unit will be charged to the user.
Please note that the HIFACE EVO TWO is not provided with a power switch, therefore it will
power on as soon as a power supply is connected to it, lighting the display (Fig. 1, 1) and
showing the operation status info.
HIFACE EVO TWO and other equipment must
HIFACE EVO TWO HIFACE EVO TWO
HIFACE EVO TWO and/or other units.
HIFACE EVO TWO HIFACE EVO TWO
HIFACE EVO TWO at its supply HIFACE EVO TWO HIFACE EVO TWO
15
