5. Connecting and powering the unit

ADVICE: all connections to other equipment in the system must be done when all
equipment are off. Failing to comply to this advice may expose the Joplin
of damages.
ADVICE: Windows users must install the driver prior to connecting the Joplin
PC (please refer to section 6).
Please refer to section 3, "Back Panel Description".
Connect the "B" plug of a 2.0 USB A-B cable to the USB connector (Figure 2, 10) of the
Joplin.
Connect the "A" plug of the cable to a 2.0 USB port of your computer.
Connect two interconnects to the analog inputs of the Joplin (Figure 2, 4/5) and to the
outputs of your analog source (be it a turntable, a tuner, a tape recorder or even the tape
rec output of your amplifier).
Connect a digital cable with suitable termination (RCA, XLR or optical Toslink™) from the
Joplin to your amplifier's digital inputs or to a DAC (Figure 2, 6/7/9).
If you need to route the output of a digital source to your computer or to the amplifier, you
may connect the source to the Joplin using an RCA digital interconnect (Figure 2, 8).
Connect the wall adaptor provided with the Joplin or any other 15V/500mA power supply
to the supply connector (Figure 2, 11) of the Joplin.
