7. Using the Evo DAC 3

At activation, the Evo DAC 3 performs a routinary check for all indicators, then it sets idle
ready for commands.

7.1. Volume Setting

Volume setting is done by either pushing the VOL+/VOL- buttons on the front panel (item
6/7, Figure 1), by pushing the VOL+ e VOL- keys on the remote control or using the free
app for Android and iOS provided by Manunta by M2Tech.
Volume can be set from -101dB (minimum) to 0dB (maximum) in 0.5dB steps.
As the Evo DAC 3 is not provided with any display, the volume level is not indicated.
Anyway, the app will show it, therefore it's a good choice to use the app to control the Evo
DAC 3.

7.2. Mute Toggle

The Evo DAC 3 is provided with a feature (muting) which allows for immediately lowering of
the listening level by 20dB without touching the encoder knob. This feature is useful when
it is necessary to listen to another person for a while, or to operate the source to change
track, answer the telephone, etc.
Muting is toggled by a short press of both front panel's VOL+ and VOL- buttons (item 6/7,
Figure 1).
To reset muting, repeat the operation: the original listening level will be immediately
restored..
As an alternative it is possible to toggle mute on and off by pushing the "MUTE" key on the
remote control or on the app's button.
WARNING: pay attention to the volume setting when the muting is active: if volume
is raised too much, once the muting is reset the listening level could be too high so
as to damage the speakers or even the listener's ears. It is always wiser to limit
volume when in mute mode and even when turning on and off the Evo DAC 3.

7.3. Source Selection

The Evo DAC 3 is provided with various inputs, therefore it is possible to connect different
sources and select which one to listen to. To select a source, press the front panel's left
button shortly.
