- Page 1 Ｉｎｓｔａｌｌａｔｉｏｎ Iｎｓｔｒｕｃｔｉｏｎｓ...
- Page 2 Nightstand Version:08/26/2022 1/20...
- Page 3 2/20...
- Page 4 C x 19+1 A x 8 B x 19+1 D x16 E x 4 4 x 12 mm 6 x 35 mm 15 x 10 mm 5 x 40 mm G x 3 F x 6 H x 4 I x 1 J x 24+1 3 x 12 mm 4 x 16 mm...
- Page 5 4/20...
- Page 6 5/20...
- Page 7 D x 16 H x 4 4 x 12 mm 4 x 12 mm 3 x 12 mm 3 x 14mm Fix leg(H) to board 3 with screw(D) as shown. 6/20...
- Page 8 J x 12 CL x 3 CR x 3 3 x 12 mm 3 x 12 mm 3 x 14mm Fix slide rail(CL) and (CR) to board 1 and 2 respectively with screw(J) as shown. Please pay attention to the holes where the accessories are inserted.
- Page 9 E x 4 J x 1 A x 4 5 x 40 mm Attach board 1,2 to board 3 with wooden dowel(A) and fix with screw(E) as shown. 8/20...
- Page 10 Slide board 4 into available slots as shown. 9/20...
- Page 11 B x 4 6 x 35 mm Insert quickfit screw(B) into corresponding holes in board 5 with a screwdriver as shown. 10/20...
- Page 12 A x 4 C x 4 15 x 10 mm Cover board 5 to the assembled component with wooden dowel(A) and turn cam lock(C) clockwise to tighten as shown. 180° 11/20...
- Page 13 B x 15 6 x 35 mm Insert quickfit screw(B) into corresponding holes in board 6 with a screwdriver as shown. 12/20...
- Page 14 C x 12 15x10mm Attach board 7,8,11 to board 6, turn cam lock(C) clockwise to tighten as shown. 180° 13/20...
- Page 15 M x 3 4 x 30 mm Slide board 9 into available slots as shown. Attach board 10 to the component with screw(M) as shown. 14/20...
- Page 16 M x 12 G x 3 F x 6 4 x 30 mm 4 x 16 mm Fix handle(G) to board 6 with screw(F) as shown. Fix board 10 to the component with screw(M) as shown. 15/20...
- Page 17 C x 3 15 x 10 mm Insert cam lock(C) into board 11 and turn it clockwise to tighten as shown. 180° 16/20...
- Page 18 J x 12 DL x 3 DR x 3 3 x 12mm 3 x 12 mm 3 x 14mm Fix runner(DL) and (DR) to board 7 and 8 respectively with screw(J) as shown. Please pay attention to the holes where the accessories are inserted. 17/20...
- Page 19 Align rails, slide all drawers. 18/20...
- Page 20 L x 6 K x 6 3 x 14 mm Reiforce back board with part(K) and screw(L) as shown. 19/20...
- Page 21 20/20...
-
Page 22: Warranty Claims
WARRANTY WARRANTY CLAIMS •There is a 30-day warranty for broken furniture or any other problems that do not work properly. The warranty will start from the date of purchase which must be verified by proof of purchase. •Before making a claim, we may be able to answer your query, simply call us. Please leave your purchase order number, along with some details of the problem, if you want a replacement part. - Page 23 RETURNS CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM? PLEASE FOLLOW THE BELOW INSTRUCTIONS: •If you have purchased and have simply changed your mind, follow the retailer’s instructions for returns. DEFECTIVE ITEMS •If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance, please call us.
