Plug the meter into the PC,and turn it on.Wait for the PC to recognize the USB drive
named "Bootloader"
Dont use the instrument in a flammable and explosive environment
Used batteries for instrument replacement and discarded instruments cannot be
disposed of with household waste.Please handle in accordance with relevant
national or local laws and regulations
When there is any quality problem with the instrument or when there is a question
about using the instrument.You can contact "Finiris" online customer service or the
manufacturer, we will solve it for you in the first time
【 2.1 】 Specifications
Signal
Active current
(mA) output
Passive current
(XMT) output
Voltage (V)
output
24V loop
Frequency (Hz)
output
Current (mA)
input
Voltage (V)
input
【 2.2 】 Function Introduction
【 Conversion Of Engineering Quantity Display 】 :Signals are displayed as physical
or engineering (ie pure quantity) values,The physical quantity corresponds linearly
with the engineering quantity.For example: the current signal of 4~20mA
corresponds to 0~100, that is, 4mA corresponds to 0, 12mA corresponds to 50, and
20mA corresponds to 100. This range can be modified by parameters
1、SAFETY INSTRUCTIONS
2、PRODUCT DESCRIPTION
Range Precision
0~24mA
± （0.1%+0.005）
0~24mA ± （0.1%+0.005）
± （0.1%+0.005）
0~24V
± （0.1%+0.005）
0~24mA
0~9999Hz
±2%
0~24mA ± （0.1%+0.005）
0~30V ± （0.1%+0.005）
Max
Resolution
load
750Ω
0.01mA
0.01mA
0.01V
0.01mA
5 digits
0.01mA
0.01V
External
power supply
0~30V
��
