Summary of Contents for RNA EBC 10
- Page 1 Operating Instructions Controllers for belt drives EBC 10 EBC 10 S...
-
Page 2: Table Of Contents
Enabling the function by external components ............... 6 3.8. Status output ........................7 Connection diagram ....................... 8 View and dimensions ......................9 Connector pin assignment of the plug for EBC 10 S .............. 9 Rhein - Nadel Automation GmbH - V/-BA-EBC10-DE – 7 July 2021... - Page 3 Declaration of Conformity According to the Low-Voltage Directive 2014/35/EU and Electromagnetic Compatibility Directive 2014/30/EU We hereby declare that the product meets the following requirements: Low-Voltage Directive 2014/35/EC Electromagnetic Compatibility Directive 2014/30/EU Applied harmonised standards: DIN EN 60204 T1 EN 61439-1 Remarks: Rhein-Nadel-Automation ---------------------------------...
-
Page 4: Technical Data
Make sure that all persons working with this controller are familiar with all safety directives and observe them fully. The device described here is a controller for operation of RNA belt drives. Observe the limits indicated in the tech- nical specification. -
Page 5: Notes On Start-Up
Any work on electrical equipment of the machine/system shall be carried out exclusively by a professional electrician, or by instructed persons working under the direction and supervision of a professional electrician, according to electrotechnical rules! Observe all safety and hazard notes and signs local to the equipment! Inspect/check the electrical equipment of the machine/system periodically. -
Page 6: Setting The Maximum Speed
3.1. Setting the maximum speed Take care to make this setting with a tachometer, you will find the nominal r.p.m. on the rating plate of the motor. The magnitude of the armature voltage is only a limited indicator for motor speed, since the motor speed also de- pends on the field voltage which results from the magnitude of the local mains voltage. -
Page 7: Status Output
Enabling via voltage signal. Terminals 10 and 11 must be jumpered, be sure to remove the ENABLE jumber from the board. Use terminals 12 and 13 to connect the enabling signal. The drive starts as soon as a signal between 10 and 30 volt of direct current is available with the correct polarity. -
Page 8: Connection Diagram
4. Connection diagram Rhein - Nadel Automation GmbH - V/-BA-EBC10-DE – 7 July 2021... -
Page 9: View And Dimensions
5. View and dimensions 6. Connector pin assignment of the plug for EBC 10 S Plug pin Line Motor connection No. 1 No. 2 No. 3 No. 4 N.C. N.C. green/yellow Rhein - Nadel Automation GmbH - V/-BA-EBC10-DE – 7 July 2021... - Page 10 Rhein-Nadel Automation GmbH Reichsweg 19-23 D-52068 Aachen Phone: +49 (0) 241-5109-0 Fax: +49 (0) 241-5109-219 E-mail: vertrieb@RNA.de www.RNA.de Further RNA group companies: Further manufacturing sites of the RNA Group Manufacturing Lüdenscheid branch Manufacturing and Sales Focus: Pharmaceutical Industry Rhein-Nadel Automation GmbH Nottebohmstraße 57...
