- Page 1 M E D I C A L MINC+ ™ B E N C H T O P I N C U B AT O R Quick reference guide 12 13...
- Page 2 Standby/ON Press this button for 2 seconds to activate the device. Enable/disable incubation chamber heater a. Touch the Unlock button for 2 seconds. The MINC+ will beep on touch, and the keypad backlight will come on when the keypad is active. b.
- Page 3 Increase/decrease chamber temperature set point a. Touch the Unlock button for 2 seconds. The MINC+ will beep on touch, and the keypad backlight will come on when the keypad is active. b. Touch and release the Increase/decrease chamber temperature set point buttons for that chamber until the desired set point temperature is displayed on the chamber display screen.
- Page 4 Enable/disable flask water-level monitoring a. Touch the Unlock button for 2 seconds. The MINC+ will beep on touch, and the keypad backlight will come on when the keypad is active. b. Touch and release the Enable/disable humidification flask water-level monitoring button to toggle water-level monitoring on and off.
- Page 5 Enable/disable gas flow Turning the gas flow ON a. Touch the Unlock button for 2 seconds. The MINC+ will beep on touch, and the keypad backlight will come on when the keypad is active. b. Touch and release the Enable/disable gas flow button to toggle gas flow on and off. When activated, the chamber’s status screen will initially display the Gas purge icon, indicating that the gas flow is enabled.
- Page 6 Center console touchscreen This is the interface for DishTrace MINC+ software. USB port This is the USB port for downloading data and dish information and for DishTrace MINC+ software updates. Keypad unlock Unlock the keypad by pressing the Unlock button for 2 seconds. The MINC+ will beep on touch, and the keypad backlight will come on when the keypad is active.
- Page 7 Humidification flasks A sterile, disposable humidification flask is provided for each incubation chamber. The flasks are backlit to allows users to see the water level and the gas bubbles passing through the water. See the list of humidification flask components and installation instructions in the IFU. Chamber lid latch A latch secures the lid of each MINC+ incubator chamber.
- Page 8 Media warming chamber (MWC) This nongassed chamber is used to warm and maintain a stable temperature for test tubes of IVF media and oil. Tubes should be capped while in the media warming chamber. Media warming chamber lights These lights indicate the MWC temperature status. •...
- Page 9 Humidification flask components Humidification flask reservoir Humidification flask latch Humidification flask seal housing Humidification flask filter sleeve Disposable funnel Humidification flask T-piece Temporary support clip used when filling the flask 12 13...
- Page 10 Humidification flask installation Please refer to the Instructions for Use (IFU) for detailed indications, contraindications, warnings, and precautions. 12 13...
- Page 11 MINC+ ™ B E N C H T O P I N C U B AT O R M E D I C A L © COOK 12/2021 RH-D 63681-EN-F...
