Ordering Information; Bill Of Materials; Ordering Guide; Esd Caution - Analog Devices EVAL-SSM2317-MINI Quick Start Manual

EVAL-SSM2317-MINI

ORDERING INFORMATION

BILL OF MATERIALS

Table 2.
Qty Reference Designator
3 C1, C2, C7
2 C3, C4
1 C5
1 G1
2 L1,L2
6 P1, P2, P3, P4, P5, P6
2 R1, R2
1 R3
1 U1

ORDERING GUIDE

Model
1
SSM2317-MINI-EVALZ
1 Z = RoHS Compliant Part.
©2009 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
Description
Ceramic capacitor, 0.1 μF, 6.3 V
Ceramic capacitor, 1 nF, 10%, 5 V
Ceramic capacitor, 10 μF, 10 V
GAP
Ferrite chip, B0603, 220 Ω, 2 A
PAD1
Resistor, 100 kΩ
Resistor, 6.98 kΩ
SSM2317
Description
Evaluation Board
EB07824-0-5/09(0)
Rev. 0 | Page 8 of 8
Supplier/Part No.
Murata, GRM033R60J104KE19D
Kemet, C0603C102J5GACTU
Murata, GRM31MF51A106ZA01L
N/A
TDK, MPZ1608S221A
N/A
Panasonic, ERJ-1GEF1003C
Panasonic, ERJ-1GEF6981C
Analog Devices, SSM2317

ESD CAUTION
