LW Scientific VFA-12 Specifications

Flex Arm Systems

Vision Flex Arm

The Vision Flex Arm laboratory-grade stereoscope offers the widest view and finest
resolution of any dual-magnification stereoscope available for inspection technicians.
The Flex Arm stand has spring-loaded hinge joints with friction adjustments to hold any
position and can be easily rotated 360° when not in use. Mount it with the C-Clamp, or
screw it directly on the counter top. The Vision's larger optics produce increased width,
working distance and depth of focus. The objectives rotate internally with a convenient
control knob when changing magnification. The optional 1/2X supplementary lens doubles
your field of view, expands your magnification options and extends your working distance
to over 6 inches for hands-under work space. The 36-bulb LED variable ring light focuses
shadow-free illumination directly onto your work. The Vision Flex Arm is the best quality
dual-mag scope in the dental, electronic and industrial markets.
• Ideal for Dental, Industrial and Electronic Inspection
• Laboratory-Grade Dual-Magnification
• Clamp or Table Mount Rotates 360°
• Spring-loaded Hinged Arm Reaches 2-1/2 Feet
Obj. Power Supp. Lens
1 X 1/2 X
2 X 1/2 X
2 X None
4 X None

Paragon Flex Arm

The Paragon Flex Arm stereoscope exceeds the performance demands of dental, industrial
and laboratory technicians at an industry-leading price. The Flex Arm stand has spring-
loaded hinge joints with friction adjustments to hold any position, and can be easily rotated
360 degrees when not in use. Mount it with the C-clamp, or screw it directly on the
countertop. The Paragon's wide-field, dual-magnification optics offer high resolution and
clarity across a broad field of view. The optional 1/2X supplementary lens doubles your
field of view, expands your magnification options and extends your working distance to
over 5 inches for hands-under work space. The optional 10 watt variable fluorescent ring
light gives 360 degrees of shadow-free illumination. The Paragon Flex Arm is the ideal
combination of quality, economy and flexibility.
• Ideal Combination of Quality, Economy and Flexibility
• Dual-Magnification, Wide Field, Long WD
• Clamp or Table Mount Rotates 360°
• Lowest Cost Inspection System From LWS
Obj. Power Supp. Lens
1 X 1/2 X
2 X 1/2 X
2 X None
4 X None
On the web: www.lwscientific.com
865 Marathon Parkway - Lawrenceville, Georgia 30045 - Ph: 770-270-1394 - Fx: 770-270-2389
Mag. FOV WD
5 X 46mm 146mm
10 X 23mm 146mm
20 X 11.5mm 110mm
40 X 5.75mm 110mm
Mag. FOV WD
5 X 40mm 140mm
10 X 20mm 140mm
20 X 10mm 90mm
40 X 5mm 90mm
Part # VFA-12
Shown with optional LED-RL light and VIS-05X lens
Part#
VFA-12
VFA-13
VFA-24
PFA-12
Shown with optional FLR10V light and PAR-05X lens
Part#
PFA-12
PFA-13
PFA-24
- email: sales@lwscientific.com
Description Magnification
Vision on Flex Arm 10x / 20x
Vision on Flex Arm 10x / 30x
Vision on Flex Arm 20x / 40x
Description Magnification
Paragon on Flex Arm 10X/20X
Paragon on Flex Arm 10X/30X
Paragon on Flex Arm 20X/40X
