LW Scientific OB2MF Specifications

Observer II-D
Construction
Heavy cast alloy
Acid and reagent resistant finish
All metal gearing
Head
Standard monocular head
Bearing mounted, rotates 360°
10X/18 wide field eyepiece
Locked-in eyepiece with pointer installed
Teaching head available
Objectives
Triple nosepiece
DIN Achromatic 4X, 10X, 40XR (retractable)
Parfocal and parcentric
Color coded
Stage
Pre-drilled and tapped for optional mechanical stage
Spring-loaded slide clips included
Stage size: 122mm x 120mm
Adjustment Controls
Coarse and fine focus with tension adjustment
Adjustable stage stop
Illumination
NA 0.65 condenser
Five position disk diaphragm
Choose: 20w Tungsten, 7w fluorescent,
15w variable halogen, or cordless LED MOBI
Input 110V (220V optional)
Mirror illuminator included for field use
Accessories Included
Dust cover, mirror illuminator, two fuses, spare bulb,
manual and warranty card
Warranty
Lifetime on materials and workmanship
One year on electronic components
Dimensions and Weight
Height: 14" (355mm)
Length: 7.7" (196mm)
Width: 5.5" (140mm)
Weight: 6.8 lbs. (3.0kg)
LW Scientific
On the web: www.lwscientific.com
865 Marathon Parkway
Ph: 770-270-1394 - Fx: 770-270-2389
•
Cost-Effective Bid Scope
•
Disk Diaphragm
•
Triple Nosepiece
The Observer II-D monocular microscope is
a cost effective design for school bids. It
features durable construction, disk diaphragm,
360° rotating head, adjustable stage stop—
and more! Teachers will love the student-proof
features.
Part# * Head
OB2MT Monoc
OB2MF Monoc
OB2MM Monoc
OB2TT Teaching
OB2TF Teaching
OB2TM Teaching
*To include an add-on mechanical stage, add an "M" to the part number.
- email: sales@lwscientific.com
- Lawrenceville, Georgia 30045
Objectives Illumination
4-10-40X Tungsten
4-10-40X Fluorescent
MOBI
4-10-40X
4-10-40X Tungsten
4-10-40X Fluorescent
MOBI
4-10-40X
