LW Scientific PFA-12 Specifications

Paragon Flex Arm
Construction
Alluminum alloy metal contruction
Acid and reagent resistant finish
Head
Binocular, inclined 45°, rotates 360°
10X/20 WF eyepieces
30.5mm eye tube inside diameter
Interpupillary distance adjustment 51-81mm
Includes rubber eyeguards and dust cover
Optional 15X eyepieces
Optional 1/2x supplementary lens for long WD
Objectives (Three choices)
1X/2X, 1X/3X, or 2X/4X paired objectives
1/2X supplementary lens available
Flex Arm Specifications
Max height above table- 3 feet
Average arm height above table - 1.5 feet
Max horizontal reach - 2.5 feet
C-clamp opening - 2.25 inches
Tightening knobs for hinge joint friction
Illumination Choices
Variable fluorescent 10w ring light
Variable LED (36 bulb) ring light
Fiber optic 150w options also available
Warranty
Limited lifetime warranty on microscope
1-year warranty on illumination
1-year warranty on Flex Arm
Dimensions and Weight
Height (retracted): 27" (690mm)
Width: 4.5" (114mm)
Weight: 10 lbs. (4.5 kg)
Obj. Power Supp. Lens
1 X 1/2 X
2 X 1/2 X
2 X None
4 X None
On the web: www.lwscientific.com
865 Marathon Parkway - Lawrenceville, Georgia 30045 - Ph: 770-270-1394 - Fx: 770-270-2389
Mag. FOV WD
5 X 40mm 140mm
10 X 20mm 140mm
20 X 10mm 90mm
40 X 5mm 90mm
•
Spring-loaded Hinged Arm Reaches 2 1/2 Feet
•
Dual Magnification-Wide Field - Long WD
•
Clamp or Table Mount Rotates 360°
The Paragon Flex Arm stereoscope exceeds the
performance demands of dental, industrial, and
laboratory technicians. The Flex Arm stand has
spring-loaded hinge joints with friction adjustments
to hold any position, and can be easily rotated
360 degrees when not in use. Mount it with the
C-clamp, or screw it directly onto the counter top.
The Paragon's wide-field, dual-magnification
optics offer high resolution and clarity across a
broad field of view. The 1/2x supplementary lens
doubles your field of view, expands your
magnificaton options, and extends your working
distance to over 5 inches for hands-under work
space. The 10 watt variable fluorescent ring light
gives 360 degrees of shadow-free illumination.
The Paragon Flex Arm is the ideal combination of
quality, economy, and flexibility.
Part#
PFA-12 Paragon on Flex Arm
PFA-13 Paragon on Flex Arm
PFA-24 Paragon on Flex Arm
- email: sales@lwscientific.com
Description Magnification
10X/20X
10X/30X
20X/40X
