LW Scientific RV30A Specifications

Revelation III
Head
Binocular (Seidentopf)
Inclined 30°, rotates 360°
Dual diopter adjustment
10X/18 wide field eyepieces (10X/20HP available)
Monocular, trinocular, dual binocular and
45° sliding heads available
Interpupillary distance range 55-75mm
Nosepiece
Quadruple forward-facing nosepiece
Multiple ball bearing mounted
Objectives
DIN Achromatic or DIN Semi-Plan, anti-fungal
4X, 10X, 40X, 100XR (oil)
Parfocal, parcentric, color-coded
Stage
Mechanical stage (140mm x 140mm)
Coaxial drive controls
Range of traverse is 73mm x 43mm
Stage locking lever
Slow-close hydraulic slide finger
Focus
Coarse adjustment: range of 30mm
Fine adjustment: graduation of 2µm
Tension control knob
Illumination
Moveable Abbe condenser, NA 1.25,
rack & pinion
Iris diaphragm
Variable halogen light source (12V/20W bulb)
110V/220V switchable electronics
12V DC battery input available
Accessories Included
Three 0.5 amp fuses, mirror attachment (for field
use), blue and green filters, dust cover, immersion
oil, spare bulb, manual and warranty card
Options
Dark field, phase contrast, soft carry case
Warranty
Lifetime on materials and workmanship
One year on electronic components
Dimensions and Weight
Height: 15" (380mm)
Length: 9" (230mm)
Width: 7" (178mm)
Weight: 14 lbs. (6.4kg)
On the web: www.lwscientific.com
865 Marathon Parkway - Lawrenceville, Georgia 30045 - Ph: 770-270-1394 - Fx: 770-270-2389
•
Medical-Grade Microscope
•
Anti-Fungal Coating on All Lenses
•
Field-Ready Portable Options
The Revelation III professional-grade
microscope is a best-seller into physician and
veterinarian clinics, as well as universities and
medical schools. Equipped for performance,
its features include titanium-finished DIN
achromatic or Semi-Plan optics and a 30-year
anti-fungal coating. The Revelation III is the
choice for superior performance at a great
value!
Part #
RV30A
RV30AT Trinoc
RV30S
RV30ST Trinoc
- email: sales@lwscientific.com
Head Objectives
Binoc 4-10-40-100 Achromatic
4-10-40-100 Achromatic
Binoc 4-10-40-100 Semi-PLAN
4-10-40-100 Semi-PLAN
