LW Scientific LW-101 Specifications

Revelation 101 Inverted Microscope
Head
Binocular head
Third tube for video/photography available
Centering eyepiece
10X wide field eyepieces
15X wide field eyepiece
Nosepiece
Four-place nosepiece
Objectives
Plan 4X NA .10 objective
Achromatic 10X NA .25 objective
Plan Phase 29XR NA .65 objective
Plan 40XR NA 1.25 (oil immersion) objective
Stage
Mechanical stage
Coaxial drive controls
Focus
Coarse and fine adjustment
Racks
Adjustable condenser rack
Adjustable illuminator rack
Condenser
Abbe condenser with 20X phase
Accessories Included
Green, yellow, blue and neutral filters, dust cover,
immersion oil, manual, and warranty card
Illumination
12V/50W halogen bulb
Options
Multiple photo options
Warranty
Lifetime on materials and workmanship
One year on electronic components
Weight
18 lbs. (8.5kg)
LW Scientific
865 Marathon Parkway -
Tel: 770-270-1394 - Fax: 770-270-2389
Web: www.lwscientific.com - email: sales@lwscientific.com
LW101-PH: Trinocular model
The Inverted Microscope Revelation LW-101
is able to perform intricate and varied
applications for vital tissue cultures. It is perfect
for observation and education, or for
professional research in a clinical lab.
Pathologists, biologists, and medical
researchers naturally choose the LW-101.
Part#
LW101 Revelation III Binocular Inverted Microscope
LW101-PH Revelation III Trinocular Inverted Microscope
Lawrenceville, Georgia 30045
Description
- USA
