Revelation IIIA-DH
Dual Binocular Head
Inclined 45°
Rotates 360°
Dual diopter adjustment
10X wide field eyepieces
Nosepiece
Quadruple forward-facing nosepiece
Multiple ball bearing mounted
Objectives
DIN Achromatic or DIN Semi-Plan, anti-fungal
4X, 10X, 40X, 100XR (oil)
Parfocal, parcentric, color-coded
Stage
Mechanical stage (140mm x 140mm)
Coaxial drive controls
Range of traverse is 73mm x 43mm
Stage locking lever
Slow-close hydraulic slide finger
Focus
Coarse adjustment: range of 30mm
Fine adjustment: graduation of 2µm
Tension control knob
Illumination
Moveable Abbe condenser, NA 1.25, rack & pinion
Iris diaphragm
Variable halogen light source (12V/20W bulb)
110V/220V switchable electronics
12V DC battery input available
Accessories Included
Three 1 amp fuses, mirror attachment (for field
use), blue and green filters, dust cover, immersion
oil, spare bulb, manual and warranty card
Options
Dark field, phase contrast, soft carry case
Warranty
Lifetime on materials and workmanship
One year on electronic components
Dimensions and Weight
Height: 18" (457mm)
Length: 7" (178mm)
Width: 6" (152mm)
Weight: 17 lbs. (7.7kg)
On the web: www.lwscientific.com
865 Marathon Parkway - Lawrenceville, Georgia 30045 - Ph: 770-270-1394 - Fx: 770-270-2389
•
Ideal for Teaching/Training Environments
•
Built-in Mechanical Stage
•
PLAN flat-field optics Available
The Revelation III dual head professional laboratory
microscope is suited for the strictest research,
academic, and professional environments.
Equipped for performance, its features include
titanium finished achromatic optics and a 30 year
anti-fungal coating. The Revelation III is the choice
for superior performance at a great value!
P
a
t r
#
R
V
3
0
A
-
D
H
-
email: sales@lwscientific.com
D
e
s
r c
p i
t
o i
n
R
e
v
l e
t a
o i
n
I
I I
D
u
a
- l
B
n i
o
c
l u
r a
