LW Scientific Z2BI Specifications

Z2 Zoom
Construction
Aluminum alloy construction
Acid and scratch resistant finish
Head
Inclined 45°, rotates 360°
10X/20 WF high point eyepieces with rubber eyeguards
Interpupillary distance 47-78mm
Trinocular available with three eye tubes live
Objectives
0.65X to 4.5X hard-coated zoom objectives
Standard magnification range is 6.5X to 45X
Maximum magnification 225X
Focus
Large dual focusing knobs with metal
rack & pinion
Metal pinion gear zoom mechanism
Maximum height 10" (250mm)
Illumination
Dual illuminators with independent switches
Variable halogen incident light: 12V/20W (MR-11)
Fluorescent transmitted light: 110V/5W
Stage
Frosted glass stage plate
Black & white contrast plate included
Power
110V AC (220V optional), 2 amp fuse
Options
Boom stands, fiber optics, high power lenses
See pages 18-20 for complete list of accessories
Warranty
Lifetime on materials and workmanship
One year on electronic components
Dimensions and Weight
Height: 15" (380mm)
Length: 11" (280mm)
Width: 8" (203mm)
Weight: 12 lbs. (5.4kg)
Part# Head
Z2BI Binoc
Z2TR Trinoc
Z2BI-BM Binoc
Z2T R-BM Trinoc
On the web: www.lwscientific.com
865 Marathon Parkway - Lawrenceville, Georgia 30045 - Ph: 770-270-1394 - Fx: 770-270-2389
Illumination
Stand
Top/Bottom
Halogen/
Pole Base
Fluorescent
Halogen/
Pole Base
Fluorescent
Optional
Boom Stand
see pp.18-20
Optional
Boom Stand
see pp. 18-20
• Industrial/Laboratory Grade
• Zoom Magnification from 6.5X to 45X
• Trinocular Head Boasts "All Three Live"
Starting with CAD design techniques, we have
manufactured the new Z2 to exceed the clarity
and quality of any zoom microscope available
today. The depth of focus, field flatness, zoom
parfocality and long working distance improve
inspection accuracy and flexibility. The high point
eyepieces offer ergonomic comfort and allow
users to wear eyeglasses. The mechanical two-
finger operation is smooth and easy to use,
reducing hand strain and improving productivity.
The Z2 is the premium choice for industrial
inspection or laboratory dissection.
Obj. Power Supp. Lens
.65 X
4.5 X
.65 X
4.5 X
- email: sales@lwscientific.com
Mag. FOV
1/2 X 3.25 X 70mm
1/2 X 22.5 X 9.2mm
None 6.5 X 35mm
None 45 X 4.6mm
WD
174mm
174mm
103mm
103mm
