Introduction
The DVK−SIP−SFxx−y−GEVK kit is a quick start solution for the
®
development of Sigfox
applications using the AX−SIP−SFxx−y
System in Package (SiP).
The xx in the part numbers in this document refers to: xx = EU
which corresponds to Sigfox region RC1. The y is for the revision.
The y in the part numbers refers to the current version of the kit.
Usage
Customers can communicate with the AX−SIP−SFxx−y SiP by
terminal emulation software or with an external micro−controller to
test Sigfox connectivity and to develop their application using the
pre−programmed AT command set as documented in the
corresponding product datasheets.
Kit Contents
•
1 Mini−module with AX−SIP−SFxx−x SiP and SMA Connector
•
1 Debugger Interface with Ribbon Cable
•
1 Mini−USB Cable
•
1 SMA Antenna
© Semiconductor Components Industries, LLC, 2017
March, 2018 − Rev. 0
EVAL BOARD USER'S MANUAL
Figure 1. DVK Boards
1
www.onsemi.com
Publication Order Number:
EVBUM2550/D
