Danfoss ET4400 Operator's Manual page 43

WARNING!
Risk of squeezing!
When the die system closes, there is a risk of getting squeezed
between the dies.
•
Only replace the intermediate dies when the machine is
deactivated.
3. Use the supplied die wrench (3) to push and hold the locking
bolt backward in the basic die (1).
4. Place the intermediate dies into the mounting hole (4) using the
retaining bolt (2).
5. Remove the die wrench (3) to release the pressure on the lo-
cking bolt - the intermediate die is now fixed.
Always mount a complete set of identical intermediate dies with
the same label and diameter.
Removing the intermediate dies
1. Close the crimping tool until the holes (5) are visible for using
the locking bolt.
2. Switch off the machine using the main switch and secure it
against switching on unintentionally.
WARNING!
Risk of squeezing!
When the die system closes, there is a risk of getting squeezed
between the dies.
•
Only replace the intermediate dies when the machine is
deactivated.
3. Hold the intermediate die to be removed with one hand.
4. Use the other hand to push and hold the locking bolt backward
in the basic die (1) by means of the die wrench (3).
5. Remove the intermediate die concerned.
