5.5

Replacing the intermediate dies

After forming heavy fittings, the locking bolt may be slightly slug-
gish. In this case, use a mallet to release the locking bolt by
slightly hitting on the die wrench.
Position the intermediate dies
1. Close the crimping tool until the holes (5) are visible for using
the locking bolt.
2. Switch off the machine using the main switch and secure it
against switching on unintentionally.
