Physical Description; Figure 1-1. Octal Fxo Module - ADTRAN Octal User Manual

Chapter 1. Introduction

Physical Description

1-2
The Octal and Quad FXO Modules plug into any available option slot in the
rear of the ATLAS 550 chassis. Figure 1-1 shows the Octal FXO Module.
The labels over the modular connectors refer to the corresponding ports on
the Octal and Quad FXO Modules.
Octal and Quad FXO Modules User Manual

Figure 1-1. Octal FXO Module

61200310L1-1
500 Series
