Chapter 3

OVERVIEW

61200310L1-1
Operation
All references to the Octal FXO Module in this section are
applicable to the Quad FXO Module, with the differences that the
Quad FXO Module has four ports instead of eight and is displayed
as FXO-4 in the menus.
The Octal and Quad FXO Modules are controlled by the ATLAS 550 Base
Unit terminal menu. The terminal menu allows for detailed configuration,
status, and testing of the Octal and Quad FXO Modules.
Configuration of the Octal and Quad FXO Modules is completed in two ar-
eas:
1. General configuration menus are located in the Octal and Quad FXO
Modules C
ONFIGURATION
2. Specific configuration items depending on how the option module is
used, will show up in the D
Access the terminal menu using either a VT-100 terminal attached to the
ATLAS 550 Base Unit's control port or a Telnet session established through
the Base Unit's Ethernet port. The ATLAS 550 User Manual provides detailed
instructions on each of these management approaches.
To edit items in the terminal menu, you must have the appropriate
password level. Each menu description in this section indicates
the password level required for write and read access. See "Access
Passwords" in the ATLAS 550 User Manual for detailed
information on working with passwords. Security level 0 users
can view and edit every available field. Security level 5 users can
view any field but cannot edit.
Octal and Quad FXO Modules User Manual
menu (M /FX0-8/C
ODULES
P (see Appendix A).
IAL LAN
).
ONFIG
3-1
