Octal BRI S/T Module Specifications ......................1-20 Physical Description ............................1-21 Chapter 2 Installation..........................2-23 Before Installing the Octal BRI S/T Module ....................2-23 Shipping Contents ........................... 2-23 Installing the Octal BRI S/T Module ......................2-24 Wiring ................................2-25 Power Up and Initialization .......................... 2-25 Failed Self-Test ............................
Page 14
Configuration ........................... 3-32 Test ..............................3-32 Module Alarms ............................3-32 Test Activity ............................. 3-32 ATLAS Features Used with Octal BRI S/T Module Options ..............3-32 Factory Restore ..............................3-32 Run Selftest............................... 3-33 Appendix A Dial Plan Interface Configuration ..................A-35 Index .................................Index-39...
Page 15
Figure 2-1. Installing the Octal BRI S/T Module..................2-24 Figure 3-1. Modules Menu........................... 3-28 Figure 3-2. Menu Tree for Octal BRI S/T Modules Menu............... 3-29 Figure 3-3. Octal BRI S/T Module Menu Options ................... 3-31 Figure A-1. Dial Plan Menus ........................A-35 Figure A-2.
Page 16
List of Figures Octal BRI S/T Module User Manual 61200343L1-1...
The Octal BRI S/T Module combines with the ATLAS 800 Series base unit and other ATLAS modules to support requirements calling for multiple BRI circuits. As many Octal BRI S/T Modules can be installed in a system as can be physically accommodated in the ATLAS 800 chassis. Figure 1-1 shows a sample application of the Octal BRI S/T Module.
• NT mode support • Maximum distance of 3,000 feet OCTAL BRI S/T MODULE SPECIFICATIONS Each port of the Octal BRI S/T Module conforms to the following specifica- tions: /LQH UDWH 192 kbps data rate /LQH FRGHV ASI (Alternate Space Incoding) )UDPLQJ RSWLRQV Framing per ANSI T1.601-1992...
The Octal BRI S/T Module (see Figure 1-2) plugs into any available option slot in the rear of the ATLAS 800 Series chassis. Figure 1-2. Octal BRI S/T Option Module The label over each RJ-45 connector refers to the port on the Octal BRI S/T Module. 61200343L1-1...
Chapter 2 BEFORE INSTALLING THE OCTAL BRI S/T MODULE Carefully unpack and inspect the Octal BRI S/T Module for shipping dam- ages. If you suspect damage occurred during shipping, file a claim immedi- ately with the carrier and then contact ADTRAN Technical Support (see the front pages of this manual for pertinent information).
Before installing the Octal BRI S/T Module, verify that the jumpers module are set correctly for the current port configuration (refer to Appendix A or the Octal BRI S/T Quick Start Guide for more details). Instructions for Installing the Octal BRI S/T Module...
Failed Self-Test If the Octal BRI S/T Module fails self-test, a message will be displayed on the LCD and the terminal menu self-test log during power-up. See the appro- priate ATLAS 800 Series User Manual for details.
Operation Chapter 3 OVERVIEW You can control and configure the Octal BRI S/T Module from a variety of sources, including the following: • The ATLAS 800 Series front panel, providing minimal configuration and status support • The terminal menus, allowing detailed configuration, status, and diag- nostics •...
The ATLAS 800 Series system controller automatically detects the presence of the Octal BRI S/T Module when it is installed in the system. To see the menus for the Octal BRI S/T Module via the terminal menu, use the arrow...
Displays the type of module actually installed in the slot or the type of module you plan to install in the slot. If an Octal BRI S/T Module is installed, the Type field automatically defaults to ST-BRI (the Octal BRI S/T Module).
Chapter 3. Operation Read security: 5 Displays test name if the Octal BRI S/T Module is executing a test. Press in this field to activate the menu. Enter Displays module status as either O of O . Even though a module...
Chapter 3. Operation ODULES Figure 3-3 shows the menu options available for the Octal BRI S/T Module (see also the menu tree in Figure 3-2 on page 3-29). The following sections describe these options. Figure 3-3. Octal BRI S/T Module Menu Options...
R ACTORY ESTORE ELFTEST ACTORY You can restore the factory default settings for an Octal BRI S/T Module by pressing either while the cursor is over the S number (this action restores ESTORE the factory settings for all of the module options) or while the cursor is over an individual field (this action restores factory settings only for the particu- lar field).
ELFTEST , a submenu of the ATLAS 800 Series main menu item T ELFTEST executes both the Octal BRI S/T Module internal test and the ATLAS 800 Se- ries internal test. For additional information on R , see the AT- ELFTEST LAS 800 Series User Manual.
These parameters vary by the type of port selected. The following section describes the configuration options available for the Octal BRI S/T Module. The D menus are only ac- cessible when using terminal mode. To access these options, select D from the ATLAS menu.
Page 36
ERMINAL By default the terminal resistance for each port of the Octal BRI S/T Module is set at 100 Ω. For this configuration, both jumpers labeled T must...
Page 37
SPID is not significant, a SPID must be entered for each phone number. For convenience, the SPID can be set to be the same as the phone number. Octal BRI S/T Module Module does not support autoSPID detection software which some terminal adapters offer.
Page 38
Appendix A. Dial Plan Interface Configuration Octal BRI S/T User Manual 61200343L1-1...
