SB151-LB
Storage Server Barebone
User's Manual
UM_SB151-LB_v3.1_120716

Advertisement

Table of Contents
loading

Related Manuals for AIC SB151-LB

Summary of Contents for AIC SB151-LB

  • Page 1 SB151-LB Storage Server Barebone User's Manual UM_SB151-LB_v3.1_120716...

  • Page 2: Table Of Contents

    CONTENTS PREFACE ������������������������������������������������������������������������������������������� i SAFETY INSTRUCTIONS �������������������������������������������������������������������� ii Chapter 1� Prodcut Introduction ������������������������������������������������ 1 1�1 Box Content ����������������������������������������������������������������������������������������1 1.2 Specifications �������������������������������������������������������������������������������������2 1�3 General Information ���������������������������������������������������������������������������3 Chapter 2� Hardware Installation ����������������������������������������������� 6 2�1 Central Processing Unit (CPU) �����������������������������������������������������������6 2�2 System Memory ��������������������������������������������������������������������������������14 2�3 Removing and Installing Top Cover �����������������������������������������������18 2�4 Installing/ Removing a Hard Disk Drive ������������������������������������������19 2�5 Removing and Installing a PSU Module �����������������������������������������20...
  • Page 3 5�1 Method 1 (Use the BIOS setup) �������������������������������������������������������57 5�2 Method 2 (Use a Dos tool - Syscheck) �������������������������������������������60 5�3 Connect to BMC �������������������������������������������������������������������������������62 5�4 Web UI �����������������������������������������������������������������������������������������������63 5�5 Updating BMC Firmware ������������������������������������������������������������������70 Chapter 6� Hardware Introduction ������������������������������������������� 71 6�1 HARDWARE DESIGN SPECIFICATION �����������������������������������������������71 6�2 Drive Slot Map �����������������������������������������������������������������������������������73 Chapter 7�...
  • Page 4 Copyright © 2016 AIC, Inc� All Rights Reserved� This document contains proprietary information about AIC products and is not to be disclosed or used except in accordance with applicable agreements.

  • Page 5: Preface

    AIC shall not be liable for technical or editorial errors or omissions contained herein. The information provided is provided "as is" without warranty of any kind. To the extent permitted by law, neither AIC or its affiliates, subcontractors or suppliers will be liable for incidental, special or consequential damages including downtime cost;...

  • Page 6: Safety Instructions

    SAFETY INSTRUCTIONS • Before getting started, please read the following important cautions: • All cautions and warnings on the equipment or in the manuals should be noted. • Most electronic components are sensitive to electrical static discharge. Therefore, be sure to ground yourself at all times when installing the internal components.
  • Page 7 • product, voltage and current marked on the product’s electrical ratings label. The voltage and current rating of the cord should be greater than the voltage and current rating marked on the product. • If the equipment is not used for a long time, disconnect the equipment from mains to avoid being damaged by transient over-voltage.

  • Page 8: Chapter 1� Prodcut Introduction

    • Enclosure( Power supply, fan, 16 x 3.5'' HDD tray included) • 3.5’’ HDD Tray • Power cord • Screws kit x 1pcs • (Include console serial cable) • Slide rail x 1set ♦ PACKAGE CONTENT MAY VARY PER REGION. SB151-LB User's Manual...

  • Page 9: 1.2 Specifications

    Chapter 1 Product Introduction 1.2 Specifications SB151-LB User's Manual...

  • Page 10: 1�3 General Information

    Chapter 1 Product Introduction 1�3 General Information SB151-LB is a 1.5U rackmount chassis with 16 x 3.5”HDD hot swap Bays at Top and single 12G expander on HDD Backplane which is a high performance server storage product. • Front Panel System power on/off and system reset 2 drawers, each loads 8 x 3.5”...
  • Page 11 Chapter 1 Product Introduction • Rear Panel 2 x8 PCIe 3.0 slots 750W 1+1 redundant PSU 80+ Gold SB151-LB User's Manual...
  • Page 12 Chapter 1 Product Introduction • Major Components 750W 1+1 redundant PSU 80+ Gold AIC Server Board Libra AIC Server Board Libra 4 x 6038 PWM easy swap fans 4 x 6038 PWM easy swap fans Two drawers, each supports 8 x 3.5” drives...

  • Page 13: Chapter 2� Hardware Installation

    • Proceed to screw 2 and loosen it by giving it two rotations and stop (see letter B). Similarly, loosen screws 3 and 4. Repeat steps A and B by giving each screw two rotations each time until all screws are loosened. • Lift the heatsink straight up (see letter C). SB151-LB User's Manual...
  • Page 14 2.1.2.1 Unlatch the CPU Load Plate • Push the lever handle labeled “OPEN 1st” (see letter A) down and toward the CPU socket. Rotate the lever handle up. • Repeat the steps for the second lever handle (see letter B). SB151-LB User's Manual...
  • Page 15 2.1.2.2 Lift open the Load Plate • Rotate the right lever handle down until it releases the Load Plate (see letter A). • While holding down the lever handle, with your other hand, lift open the Load Plate (see letter B). SB151-LB User's Manual...
  • Page 16 The processor must align correctly with the socket opening before installation. DO NOT DROP the processor into the socket. NOTE : When possible, a CPU insertion tool should be used when installing the CPU. SB151-LB User's Manual...
  • Page 17 Make sure the load plate tab engages under the socket lever when fully closed. • b.Repeat the steps to latch the locking lever on the other side (see letter C). Latch the levers in the order as shown. SB151-LB User's Manual...
  • Page 18 (see letter D). Similarly, engage screws 3 and 4. • Repeat steps C and D by giving each screw two rotations each time until each screw is lightly tightened up to a maximum of 8 inch-lbs torque (see letter E). CAUTION: Do not over-tighten fasteners. SB151-LB User's Manual...
  • Page 19 Remove the processor by carefully lifting it out of the socket, taking care NOT to drop the processor and not touching any pins inside the socket. Install the socket cover if a replacement processor is not going to be installed. SB151-LB User's Manual...
  • Page 20 Caution - Possible thermal damage. Avoid moving the heatsink after it has contacted the top of the CPU. Too much movement could disturb the layer of thermal compound, causing voids, and leading to ineffective heat dissipation and component damage. SB151-LB User's Manual...

  • Page 21: 2�2 System Memory

    Slot 3 Slot 2 Slot 1 JBMC_DP note : Slot 1 / Slot 2 /Slot 3 Available ONLY When JCPU0 processor is installed. Slot 4 / Slot 5 /Slot 6 Available ONLY When JCPU1 processor is installed. SB151-LB User's Manual...
  • Page 22 JDIMMD1 JDIMMF0 JDIMMD0 JDIMME1 JDIMMC1 JDIMMC0 JDIMME0 JDIMMG0 JDIMMA0 JDIMMG1 JDIMMA1 JDIMMB0 JDIMMH0 JDIMMB1 JDIMMH1 CPU1 CPU0 JDIMM_G0 JDIMM_A0 8 DIMMs JDIMM_H0 JDIMM_B0 CPU0 CPU1 JDIMM_F0 JDIMM_D0 JDIMM_E0 JDIMM_C0 JDIMMF1 JDIMMD1 JDIMMF0 JDIMMD0 JDIMME1 JDIMMC1 JDIMME0 JDIMMC0 SB151-LB User's Manual...
  • Page 23 JDIMMA0 CPU1 CPU0 JDIMMG1 JDIMMA1 JDIMMH0 JDIMMB0 JDIMM_G0 JDIMM_A0 JDIMMH1 JDIMMB1 JDIMM_G1 JDIMM_A1 JDIMM_H0 JDIMM_B0 16 DIMMs JDIMM_H1 JDIMM_B1 CPU0 CPU1 JDIMM_F1 JDIMM_D1 JDIMM_F0 JDIMM_D0 JDIMM_E1 JDIMM_C1 JDIMMF1 JDIMMD1 JDIMMF0 JDIMMD0 JDIMM_E0 JDIMM_C0 JDIMME1 JDIMMC1 JDIMME0 JDIMMC0 SB151-LB User's Manual...
  • Page 24 2.2.2 DIMM Installation Procedure Unlock a DIMM socket by pressing the retaining clips outward. Insert module vertically and press down until it snaps into place. Note: DIMM notch and socket bump must align as shown. DIMM notch SB151-LB User's Manual...

  • Page 25: 2�3 Removing And Installing Top Cover

    Chapter 2 Hardware Installation 2�3 Removing and Installing Top Cover Loosen 10 screws on top cover. Take it out of the enclosure. SB151-LB User's Manual...

  • Page 26: 2�4 Installing/ Removing A Hard Disk Drive

    2. Remove the screw holding the hard drive tray in place. These screws cannot be removed completely from the tray. They are fastened to the tray to avoid loss. Grab the hard drive and pull to remove. SB151-LB User's Manual...

  • Page 27: 2�5 Removing And Installing A Psu Module

    Slide the small levers (see red arrow ) to the right. Hold the PSU lever and firmly pull the PSU out of the server chassis. 2.5.2 Installing a PSU Module • To install PSU module, follow the reverse order. SB151-LB User's Manual...

  • Page 28: 2�6 Removing And Installing A Fan Module

    NOTE: The heat sink’s fans should be blowing toward the rear end of the chassis. If one of the fans is facing the wrong direction, please remove the heat sink and reinstall it so that it is facing the correct direction. SB151-LB User's Manual...
  • Page 29 Pull the fan module up gently and taking out the fan module by removing rubbers out from the fan bar. 2.6.2 Installing a Fan Module Make sure the 4 rubbers and connector insert firmly while fan module is inserted. SB151-LB User's Manual...

  • Page 30: 2�7 Removing And Installing The Hdd Backplane Module

    • Grasp and lift up the blackplane then can get out. 2.7.2 Installing a HDD backplane module • Slide the HDD backplane module into enclosures. • Secure the HDD backplane module onto the enclosures using the screws. Follow the reverse order. SB151-LB User's Manual...

  • Page 31: 2�8 Removing And Installing A 2�5-Inch Ssd

    HDD match the dimples on the cage. Push th HDD with force to hold the spring backward and lift it up to release it. Then place the other side of HDD into the cage until it clips. rear bracket SB151-LB User's Manual...

  • Page 32: 2�9 Removing And Installing A Pcie Card

    2.9.1 Removing a PCIe Card (Slot 6) • Loosen the two captive screws securing the riser card to the chassis. • lift the riser card. SB151-LB User's Manual...
  • Page 33 2.9.2 Removing a PCIe Card (Slot 6) • Remove filler panel from the riser card slot. • Insert the new PCIe card into the riser assembly and fasten the screw to secure the card. • To install PCIe Card, follow the reverse order. SB151-LB User's Manual...
  • Page 34 Chapter 2 Hardware Installation 2.9.3 Removing a PCIe Card (Slot 4 or Slot 5) • Loosen the two captive screws securing the riser card to the chassis. • lift the riser card. SB151-LB User's Manual...
  • Page 35 • Remove filler panel from the riser card slot. • Insert the new PCIe card into the riser assembly and fasten the screw to secure the card. • To install the PCIe Card, follow the reverse order. SB151-LB User's Manual...

  • Page 36: 2.10 Configure The Sas Signal Link Setting

    Insert one end of the SFF-8643 to SFF-8643 cable into expander borad ports of the barebone. Insert the other end of the SFF-8643 to SFF-8643 cable into the corresponding expander borad ports on site of the barebone. Drawer 1 Drawer 1 SB151-LB User's Manual...

  • Page 37: 2�11 Removing And Installing A Rj45 Module

    1. Remove PCI Bracket Slot Cover. SEE 2.9 Removing and Installing a PCIe Card 2. Take the RJ45 module insert the either one slot onto the chassis. 3. Be sure the RJ45 module insert to chassis properly. SB151-LB User's Manual...
  • Page 38 1. Punch out additional flashing on the I/O shield to make room for RJ45 module. 2. Align the module to the top and botton of the I/O shield for correct direction. 3. Secure the RJ45 module on the I/O shield using the screws. SB151-LB User's Manual...
  • Page 39 2.11.2 Configure the RJ45 function setting LAN3 Insert one end of the cable into port of the barebone. Insert the LAN4 other end of the cable into the corresponding port on site of the barebone. 1. Type 2. Type SB151-LB User's Manual...

  • Page 40: 2�12 Tool-Less Blade Slide Installation Introduction

    Chapter 2 Hardware Installation 2�12 Tool-less Blade Slide Installation Introduction 1. Pull on the ‘’Front-Release’’to unlock the inner channel from the Slide Assembly. 2. Release the Detent-Lock and push Middle Channel inwards to retract Middle Channel. SB151-LB User's Manual...
  • Page 41 Chapter 2 Hardware Installation Optional: Remove Metal Spacer for Aluminium Racks Metal Spacer 3. Aligning the Front Bracket with the Mounting Hole. 4. Push in to assembly the Front Bracket onto the Rack. SB151-LB User's Manual...
  • Page 42 Chapter 2 Hardware Installation 5. Now the bracket is fixed onto the Rack. (Optional M6x10L screws are to secure the rails with posts if needed.) 6. Refer to Diagram 3. & 4. to assemble the End Bracket onto the Rack. SB151-LB User's Manual...
  • Page 43 Chapter 2 Hardware Installation 7. Assemble the inner channel onto the chassis using thescrews provided. 8. Push the chassis with inner channels into Slide to complete Rack Installation. SB151-LB User's Manual...

  • Page 44: Chapter 3� Motherboard Settings

    Chapter 3 Motherboard Setting Chapter 3� Motherboard Settings This section describes the jumpers, internal connectors, and internal LEDs setting on Libra motherboard. Motherboard layout and important jumper settings are listed as below. 3�1 Motherboard block diagram SB151-LB User's Manual...

  • Page 45: 3�2 Motherboard Block Diagram

    PCIe slot3 JBAT JSGPIO SATA2 SATA1 JSSGPIO JCMOS JPCH_GPIO SATA4 SATA3 JNTB PCIe slot2 JLPC_DP SATA6 SATA5 I210 I217 JSPKR1 SATA8 SATA7 PCIe slot1 JUSB_INT JNGFF JBMC_RST JBMC_DIS JBMC_DP JFRNT_SSI JLAN1 JLAN2 JLAN2 JCOM4 JLCM JINTRUDERJ BMC_I2C1 SB151-LB User's Manual...

  • Page 46: 3�3 Motherboard Content List

    Chapter 3 Motherboard Setting 3�3 Motherboard Content List SB151-LB User's Manual...

  • Page 47: 3�4 Internal Connectors/Jumpers

    JDIMMD0 JDIMMC1 JDIMMC0 JPG_LOOK1 JSPI JBUZZER JDOM_PWR JPWR3 JBMC_GPIO JTPM JSGPIO JSSGPIO JCMOS JPCH_GPIO JNTB JLPC_DP JUSB_INT JSPKR1 JNGFF JUSB_INT JFRNT_SSI JBMC_RST JBMC_DIS JBMC_DP JFRNT_SSI JLAN1 JLAN2 JCOM4 JLCM JINTRUDER JBMC_I2C1 JPMBUS PWM4 FAN7_TACH +12V HM_TD7- HM_TD7+ SB151-LB User's Manual...
  • Page 48 Chapter 3 Motherboard Setting JPWR3 JDOM_PWR JPG_LOOK1 JUSB_INT SB151-LB User's Manual...
  • Page 49 JBAT JSGPIO SATA2 SATA1 JSSGPIO JCMOS JPCH_GPIO SATA4 SATA3 JNTB JLPC_DP SATA6 SATA5 JSPKR1 SATA8 SATA7 JNGFF JUSB_INT JBMC_RST JBMC_DIS JBMC_DP JFRNT_SSI JLAN1 JLAN2 JCOM4 JLCM JINTRUDER JBMC_I2C1 JTPM JSGPIO JSSGPIO JCMOS JNTB JSPKR1 SB151-LB User's Manual JLAN1 JLAN2 JCOM4...
  • Page 50 Chapter 3 Motherboard Setting JTPM JSGPIO JSSGPIO +3.3V PCH_SPI_MISO PCH_SPI_MOSI PCH_SPI_CLK PCH_GPIO23 PCH_SPI_CS1_N PCH_LDRQ0_N PCH_SPI_CS2_N RST_PLTRST_N JSPKR1 JLAN2 JLAN1 JLAN4 SB151-LB User's Manual...
  • Page 51 JDOM_PWR JPWR3 JBMC_GPIO JTPM JBAT JSGPIO SATA2 SATA1 JSSGPIO JCMOS JPCH_GPIO SATA4 SATA3 JNTB JLPC_DP SATA6 SATA5 JSPKR1 SATA8 SATA7 JNGFF JUSB_INT JBMC_RST JBMC_DIS JBMC_DP JFRNT_SSI JLAN1 JLAN2 JCOM4 JLCM JINTRUDER JBMC_I2C1 JPCH_GPIO JLPC_DP JNGFF JBMC_DP JLCM SB151-LB User's Manual...
  • Page 52 Chapter 3 Motherboard Setting JLPC_DP PCH_GPIO21 JPCH_GPIO PCH_GPIO27 JBMC_DP JLCM SB151-LB User's Manual...
  • Page 53 Chapter 3 Motherboard Setting SB151-LB User's Manual...
  • Page 54 Chapter 3 Motherboard Setting JNGFF SB151-LB User's Manual...
  • Page 55 JBMC_I2C10 JBUZZER JPWR3 JDOM_PWR PCIe slot4 LSISA JBMC_GPIO JTPM S3008 PCIe slot3 JSGPIO JSSGPIO JCMOS JPCH_GPIO JNTB PCIe slot2 JLPC_DP I210 I217 JSPKR1 PCIe slot1 JUSB_INT JNGFF JBMC_RST JBMC_DIS JBMC_DP JINTRUDER JFRNT_SSI JLAN1 JLAN2 JCOM4 JLCM JBMC_I2C1 SB151-LB User's Manual...
  • Page 56 Chapter 3 Motherboard Setting JPWR1 JVGA_INT JPMBUS +12V DACROA DACGOA +12V DDC_DATAO +12V DACBOA AHSYNCO +12V DVO_5V AVSYNCO DDC_CLKO JBMC_I2C10 JBUZZER JBMC_GPIO BMC BUZZER- I2C10SDA I2C10SCL JBMC_I2C1 SB151-LB User's Manual...

  • Page 57: 3�5 Leds

    Chapter 3 Motherboard Setting 3�5 LEDs 3.5.1 Front Panel LED SB151-LB User's Manual...
  • Page 58 Chapter 3 Motherboard Setting 3.5.2 Rear Panel LED SB151-LB User's Manual...
  • Page 59 Chapter 3 Motherboard Setting 3.5.3 Internal LEDs LED4 LED1 LED3 LED2 SB151-LB User's Manual...

  • Page 60: Chapter 4. Bios Configuration And Settings

    Press ESC to run the setup procedure. There will be a message “Entering SETUP” displayed on the diagnostics screen. Caution: For the official released version, the last digit of the BIOS Version must end in an "0." SB151-LB User's Manual...
  • Page 61 Chapter 4 BIOS Configuration and Settings Identify the BIOS Version Load Optimal Default setting Save the setting and exit the BIOS setup utility. SB151-LB User's Manual...

  • Page 62: 4�1 Updating Bios

    Chapter 4 BIOS Configuration and Settings 4�1 Updating BIOS Important Notes: To identify the current BIOS version, please check out on BIOS setup. SB151-LB User's Manual...
  • Page 63 H2OFFT-D utility. To use this utility, you must include the flash.bat , H2OFFT-D.exe, and bin file in the same folder. Please follow the instructions to update whole flash part: Execute flash.bat to update Flash in the DOS environment. Reboot system. SB151-LB User's Manual...

  • Page 64: Chapter 5

    BMC Configuration and Settings Insert Ethernet LAN cable into the BMC LAN port. There are two methods to setup BMC IP: BMC management port 5�1 Method 1 (Use the BIOS setup) • BIOS SETUPServer MgmtBMC network configurationConfiguration Address sourceStatic SB151-LB User's Manual...
  • Page 65 Chapter 5 BMC Configuration and Settings 2. Input IP address. Set static IP. SB151-LB User's Manual...
  • Page 66 Chapter 5 BMC Configuration and Settings 3. Input subnet mask address. SB151-LB User's Manual...

  • Page 67: 5�2 Method 2 (Use A Dos Tool - Syscheck)

    5�2 Method 2 (Use a Dos tool - Syscheck) 1. Type : sc –lanset 2. Modify IP setting Note: type 1 for selecting static IP mode or type 2 for selecting DHCP mode. 3. Input IP address SB151-LB User's Manual...
  • Page 68 Below IP address is an example using a default IP setting. User is allowed to change the IP address for realistic use. 5. Finish BMC IP configuration. Note: Type sc.exe –langet command to obtain BMC IP and MAC address. SB151-LB User's Manual...

  • Page 69: 5�3 Connect To Bmc

    Password: admin Note: The default user name and password are in lower-case characters. Note: Users who login with the admin user name and password will have full administrative power. The admin password can be changed after login. SB151-LB User's Manual...

  • Page 70: 5�4 Web

    A graphical representation of all events incurred by the various sensors and % occupied/available space in logs. If you click on the color- coded rectangle in the Legend for the chart, you can view a list of those specific events only. SB151-LB User's Manual...
  • Page 71 • Product Part Number • Language • Product Version • Manufacture Date Time • Product Serial Number • Board Manufacturer • Asset Tag • Board Product Name • FRU File ID • Board Serial Number • Product Extra SB151-LB User's Manual...
  • Page 72 Chapter 5 BMC Configuration and Settings 5.4.3 Sensor Modification Enable/disable sensors to match your system configuration. After modify sensors, please clear all logs via this BMC WEB GUI. Server HealthgEvent LoggClear All Event Logs). SB151-LB User's Manual...
  • Page 73 Chapter 5 BMC Configuration and Settings 5.4.4 Sensor reading All sensor related information will be displayed here. Double click on a record to loggle(ON/OFF)the live widget for that particular sensor. SB151-LB User's Manual...
  • Page 74 Event Log. Clear All Event Logs Clear All Event Logs option will delete all existing records for all sensors. Save All Event Logs Save All Event Logs option will save all existing records for all sensors. SB151-LB User's Manual...
  • Page 75 Icon status Green: This slot inserted HDD and power on. Blue: This slot inserted HDD and power off. Red: This slot inserted HDD and got error. Gray: This slot not inserted HDD. Orange: This slot is rebuilding. SB151-LB User's Manual...
  • Page 76 Chapter 5 BMC Configuration and Settings 5.4.7 Remote Control: Environmental setting: Press “ALT+C” for local and remote OS mouse control switching. SB151-LB User's Manual...

  • Page 77: 5�5 Updating Bmc Firmware

    A:>cd 301C01 A:\ 301C01>a.bat This is just an example. The latest BMC firmware version is available from the FAE or AIC website. 4. After update BMC firmware, please power off and then power on system. Notes: 1. DO NOT USE EMM386 IN DOS ENVIRONMENT WHEN UPDATING FIRMWARE OR YOU WILL GET A FAIL.

  • Page 78: Chapter 6� Hardware Introduction

    SASHD JPWR JFAIL_IN JFAIL_OUT HDD1 HDD2 HDD3 HDD1 6.1.2 Internal Connectors/Jumpers Led status Header - JLED_IN Description Description HDD1_ACT HDD1_FAIL HDD2_ACT HDD2_FAIL HDD3_ACT HDD3_FAIL HDD4_ACT HDD4_FAIL Led Fail status Header – JFAIL_IN Description FAIL_IN_1 FAIL_IN_2 FAIL_IN_3 FAIL_IN_4 SB151-LB User's Manual...
  • Page 79 Access LED from SGPIO. Open Identify behavior according to Host. Close Blinking the Identify LED behavior. Open Disable SGPIO. Close Enable SGPIO. Note: For Expander jumper: JSGPIO_SET [2] [3,4] [6][8] For HBA/RAID card : JSGPIO_SET [2] [3,4] [6][7,8] SB151-LB User's Manual...

  • Page 80: 6�2 Drive Slot Map

    Chapter 6 Hardware Instruction 6�2 Drive Slot Map FIRST LEVEL HBA Card SENCOND LEVEL HBA Card AND SO ON FIRST LEVEL MegaRaid Card AND SO ON SB151-LB User's Manual...

  • Page 81: Chapter 7� Technical Support
