• Port 0 APS MEP
• Port 1 APS MEP
• Ring Type
• Major Ring ID
• Alarm
Buttons
: Click to refresh the page immediately.
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.

4.7.1.4 Ethernet Ring Protocol Switch Configuration

This page allows the user to inspect and configure the current ERPS Instance; screen in
ring instances. "0" in this field indicates that no Port 1 SF MEP is associated with
this instance.
The Port 0 APS PDU handling MEP.
The Port 1 APS PDU handling MEP. As only one APS MEP is associated with
interconnected sub-ring without virtual channel, it is configured as "0" for such
ring instances. "0" in this field indicates that no Port 1 APS MEP is associated
with this instance.
Type of Protecting ring. It can be either major ring or sub-ring.
Major ring group ID for the interconnected sub-ring. It is used to send topology
change updates on major ring. If ring is major, this value is same as the
protection group ID of this ring.
There is an active alarm on the ERPS.
: Click to add a new Protection group entry.
User's Manual of IGS-5225-8T2S2X & 8P2S2X series
360
Figure 4-7-1-4 appears.
