1. INTRODUCTION
The MAGPOWR Spyder™ Configuration Tool allows the parameters from a MAGPOWR Model Spyder to be saved
and retrieved from a file on a PC. This will allow backing up of a Spyder's data and calibrations and may be used to
copy setup data from one Spyder to another.
2. HARDWARE CONNECTIONS
Connect the Spyder to a computer using a CAT5 Ethernet cable. Multiple Spyders may be connected to a single
computer by using a network hub or switch.
