Technical Information
PLUS+1 DM1x00 Series Displays
Installation

Visibility and viewing radius

Optimal viewing angle

Display faulty application recovery

Cleaning

© Danfoss | October 2021
Due to the display nature of the TFT-LCD screen, the optimal viewing angle for the DM1x00 series
displays are at a maximum radius of 85° from either side of the screen.
The boot loader is always executed when the unit is powered. The boot loader checks if the application
has the completely downloaded flag set and in that case starts to execute it after a delay of 200 ms. The
delay gives an opportunity for the PLUS+1
a non functional application to be replaced by the boot loader. This recovery function is activated by the
Communication > Recover ECU menu in the PLUS+1
Do not pressure wash. Clean using a dry, soft, lint-free cloth, such as a micro-fiber cloth.
85°
® Service Tool to prevent the call to the application. This allows
® Service Tool.
BC313277849405en-000204 | 27
