Can Shield And Analog Input; Digital Output; Can Communication - Danfoss PLUS+1 DM1 00 Series Technical Information

Technical Information
PLUS+1 DM1x00 Series Displays
Input/output types and specifications

CAN shield and analog input

Digital output

CAN communication

16 | © Danfoss | October 2021
CAN Shield
Description Unit
Input impedance —
Analog input
Description Unit
Minimum discernible V
voltage
Maximum discernible V
voltage
Resolution mV
Worst case offset and gain V
error
Non-linearity mV
Input impedance kΩ
Low side digital output
Description Unit
Voltage V
Current mA
Description Unit
Available Baud rates kbps
Maximum input voltage V
range
Software updates using CG150 are supported via CAN0 and CAN1 channels.
Minimum Typical Maximum
— 0.68µF+1Ω —
Minimum Typical Maximum
— — 0.03
5.64 5.78 5.92
— 1.4 —
— — ±0.14
— — ±8.5
230 233 236
Minimum Typical Maximum
0 — Vin
0 — 500
Minimum Typical Maximum
50
100
125
250
500
1000
-27 — 40
Comment
—
Comment
—
—
—
V = 5.78 V
Measure
—
Comment
Iout = 500mA
—
Comment
With 120 Ω termination.
The default baud rate is 250
kbps.
CAN+ and CAN-
BC313277849405en-000204
