PLUS+1 DM1x00 Series Displays
Input/output types and specifications

Digital/analog

Multifunction inputs

© Danfoss | October 2021
Middle range
Description Unit
Minimum discernible V
voltage
Minimum discernible V
voltage
Resolution mV
Worst case offset and gain V
error
Non-linearity mV
Input impedance kΩ
Input impedance (5V/GND) kΩ
Input impedance (2.5V) kΩ
High range
Description Unit
Minimum discernible V
voltage
Maximum discernible V
voltage
Resolution mV
Worst case offset and gain V
error
Non-linearity mV
Input impedance kΩ
Input impedance (5V/GND) kΩ
Pull up and pull down input kΩ
impedance (2.5V)
Low range analog
Description Unit
Minimum discernible mV
voltage
Maximum discernible mV
voltage
Resolution mV
Worst case offset and gain mV
error
Non-linearity mV
Input impedance kΩ
Input impedance (5V/GND) kΩ
Input impedance (2.5V) kΩ
Minimum Typical Maximum
— 0.03
—
5.69 5.78 5.88
— 1.4 —
— — ±0.14
— — ±8.5
232 233 234
13.9 14.1 14.3
7.1 7.3 7.4
Minimum Typical Maximum
— 0.16
—
37.9 38.8 39.7
— 9.5 —
— — 0.95
— — ±56.8
109.1 109.3 109.5
13.0 13.2 13.4
6.9 7.0 7.1
Minimum Typical Maximum
— — 13
379 404 430
— 0.1 —
— — ±0.6
— — ±26
232 233 234
13.9 14.1 14.3
7.1 7.3 7.4
Comment
—
—
—
V = 5.78 V
Measure
—
No pull up or pull down
Pull up or pull down
Pull up and pull down
Comment
—
—
—
V = 38.8 V
Measure
—
No pull up or pull down
(Vin < 5.7 V)
Pull up or pull down (Vin <
5.7 V)
Pull up and pull down (Vin
< 5.7 V)
Comment
—
—
—
V = 404 mV
Measure
—
No pull up or pull down
Pull up or pull down
Pull up and pull down
