PLUS+1 DM1x00 Series Displays
Input/output types and specifications

USB communication

RS232 communication

Sensor output

Video power

Officially validated digital camera formats

© Danfoss | October 2021
Description Unit
Available Baud rates Mbps
Maximum input voltage V
USB current limitation mA
Description Unit
Available Baud rates bps
Maximum input voltage V
Description Unit
Sensor Output Voltage (5V) V
Sensor Output Voltage (8V) V
Sensor Output Current (5V) mA
Sensor Output Current (8V) mA
Description Unit
Output Voltage (12V) V
Output Voltage (24V) V
Output Current (12V) mA
Output Current (24V) mA
RTSP, RTP
IP Transport Protocol
H264, MJPEG
Video Stream Format
Minimum Typical Maximum
12 — 480
-0.3 — 7.3
250
Minimum Typical Maximum
— 9600 —
11400
19200
28800
38400
57600
115200
-25 — 25
-13.2 — 13.2
Minimum Typical Maximum
4.85 5 5.15
7.75 8 8.25
250
150
Minimum Typical Maximum
12
24
750
375
Comment
—
D+, D-, and VBUS
Comment
Rx
Tx
Comment
Comment
