Technical Information
PLUS+1 DM1x00 Series Displays

Product ratings

DM1x00 environmental testing criteria

Supply voltage/maximum current ratings

20 | © Danfoss | October 2021
Climate environment
Description
Storage temperature
Operating temperature
Thermal and humidity cycle
Degree of protection
Chemical environment
Description
Chemical resistance
Mechanical environment
Description
Vibration
Bump
Shock
Free fall
Electrical/electromagnetic
Description
EMC emissions
EMC immunity
ESD
Electrical transients
Short circuit protection
Reversed polarity protection
DM1x00 displays are designed to operate with a nominal 9 to 36 Vdc power supply with reverse polarity
protection.
Supply voltage/maximum current ratings
Description Unit
Operating temperature °C
Storage temperature °C
Applicable standard
IEC 60068-2-1, test Ab, IEC 60068-2-2 test
Bb
IEC 60068-2-1, test Ab, IEC 60068-2-2 test
Bd
IEC 60068-2-38 (partial)
IEC 60529
Applicable standard
ISO 16750-5
Applicable standard
IEC 60068-2-64 test Fh
IEC 60068-2-27 test Eb
IEC 60068-2-27 test Ea
IEC 60068-2-31 test Ed
Applicable standard
ISO 13766
ISO 13766
EN61000-4-2
ISO 7637-2, ISO 7637-3
Danfoss test
Danfoss test
Minimum Typical
-30 —
-40 —
Comment
Comment
Comment
3.17g
50g
Comment
Electromagnetic compatibility for
earth moving machinery.
Electromagnetic compatibility for
earth moving machinery.
Inputs and outputs survive
continuous short circuit. Normal
function resumes when short is
removed.
Survives reverse polarity at supply
voltage for at least five minutes.
Maximum Comment
+70
+85
BC313277849405en-000204
