Middle range frequency (PPU) (continued)
Description Unit
Input impedance (5V/GND) kΩ
Input impedance (2.5V) kΩ
Resistance input
Description Unit
Range Ω
Measurement error %
Input impedance Ω
Current input (4-20 mA)
Description Unit
Minimum discernible mA
current
Maximum discernible mA
current
Resolution µA
Worst case offset and gain µA
error
Non-linearity µA
Input impedance Ω
Minimum Typical Maximum
13.9 14.1 14.3
7.1 7.3 7.4
Minimum Typical Maximum
6 — 10000
— — 7.1
— — 2.1
— — 5.4
1320 1320 1330
Minimum Typical Maximum
— — 0.12
28.2 28.9 29.7
— 7 —
— — ±743
— — ±42
197 200 202
Comment
Pull up or pull down
Pull up and pull down
Comment
In steps of 1 Ω
@100Ω
@1kΩ
@10kΩ
No pull up or pull down
Comment
—
—
—
I = 28.9 mA
Measure
—
No pull up or pull down
