ECS-4+
AIR INLET PRESSURE SET POINT
The air
establishes the desired room static pressure
level. When the room static pressure rises
above the static pressure set point, the air inlet
baffle board begins to open. When the static
pressure of the room drops below the static
pressure set point, the air inlet baffle board
begins to close.
The Air inlet static pressure set point is
adjusted in 0.01" H
a minimum setting of 0.00" H
setting of 14" H
Adjusting the static pressure set point:
•
rotate the Selector dial to position (7),
•
rotate the Adjustor dial counterclockwise to
decrease the relative set point, clockwise to
increase it.
The air inlet static pressure set point is
displayed on the front panel.
Example:
A static pressure set point of 0.08" H
When room pressure rises above 0.08" H
inlet timer delay has expired as set by secondary
function (8), the air inlet baffle board begins to open.
Due to a built-in 0.01" hysteresis, when the room
pressure drops to 0.07" H
expired, the air inlet baffle board begins to close.
Page 28
www.monitrol.com
inlet static pressure
O (water) increments from
2
O to a maximum
2
O
2
O
2
O , and the air
2
O , and the same timer has
2
set point
is selected.
