3onedata ICPE2300A-BW-8A25-1GC3GT-PD2P12 48 Quick Installation Manual

ICPE2300A-BW-8A25-1GC3GT-PD2P12_48
Industrial Indoor
5G Wireless Router
Quick Installation Guide
3onedata Co., Ltd.
Address: 3/B, Zone 1, Baiwangxin High Technology
Industrial Park, Xili,
Shenzhen
Website: www.3onedata.com
Tel: +86 0755-26702688
Fax: +86 0755-26703485

【Package Checklist】

Please check whether the package and accessories are intact
while using the device for the first time.
1. 5G Router x1
2. 2.4G omnidirectional antenna x2
3. 5.8G omnidirectional antenna interface x2
4. 5G Sub-6G antenna x4
5. Magnetic sucker base and connecting line x8
6. SFP slot dust cap x1
7. Din-Rail Mounting attachment x1
8. Ejection pin for SIM card
9. Warranty card
10. Certificate
If any of these items are damaged or lost, please contact our
company or dealers, we will solve it ASAP.

【Product Overview】

This product is DIN-Rail Industrial-grade Indoor 5G Wireless
Router. Model: ICPE2300A-BW-8A25-1GC3GT-PD2P12_48
(1 Gigabit COMBO port(PoE WAN) + 3 Gigabit copper ports
(LAN) + 2 2.4G antennas + 2 5.8G antennas + 4 5G Sub-6G
antennas, 12~48VDC single power and dual input).

【Panel Design】

Front view

Nanshan District,
Top view


1 / 5
Rear View
1. System indicators, from left to right in turn they are:
Running Indicator(RUN)
Alarm Indicator(ALM)
Power Supply Indicator(P1-P2)
2. WiFi Indicators, from left to right in turn they are:
2.4G wireless signal indicator (2.4G)
5.8G wireless signal indicator (5.8G)
