Specifications
Connector Specifications
6
7
8
9
10
11
12
13
14
15

2.2. External Antenna RF Connector

The external antenna connector type is a TNC RF connector AEP Connectors 6001-7051-003.
40
USB_PWR I
Ground -
PWR_IN I
DSR_IN I
TX+/RTS_OUT O
TX-/TX_OUT O
Ground -
USB_D+ I/O
USB_D- I/O
Ground -
Power Input line (USB)
Power Ground
+9 to +36 VDC Power Input
Data Set Ready (RS-232)
Transmit Data positive line (RS-422) / Request to Send (RS-
232)
Transmit Data negative line (RS-422) / Transmit Data (RS-232)
Power Ground
Positive line (USB)
Negative line (USB)
Power Ground
