Installation and Mounting:
Step 1. Consult the FORD PIU factory service manual to remove the front fascia from the vehicle.
Step 2. Fit brackets into position using existing mounting points for radiator shutters as shown in FIGURE 1.
Step 3. Fasten in position using provided (2) ¼-20 bolts shown in FIGURE 2.
Step 4. Mount desired light engine(s) to bracket as desired using provided hardware example shown in FIGURE 3.
Step 5. Repeat steps 1-4 for opposite side bracket.
Figure 1
Figure 3
Figure 2
Page 2 of 4
