Read all instructions and warnings before installing and using.
INSTALLER:
This manual must be delivered to the end user of this equipment.
INSTALLATION
& OPERATION MANUAL
MODEL CL199/299 SERIES
LED BEACON
Contents:
Page 1 of 6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Code 3 CL199 Series
Summary of Contents for Code 3 CL199 Series
-
Page 1: Table Of Contents
INSTALLATION & OPERATION MANUAL MODEL CL199/299 SERIES LED BEACON Contents: Installation & Mounting..............2 Operation..................2 Wiring Instructions................2 Class 1 ECE Wiring Instructions............4 Class 2 ECE Wiring Instructions............5 Warranty...................6 IMPORTANT: Read all instructions and warnings before installing and using. INSTALLER: This manual must be delivered to the end user of this equipment. T07890 Rev. -
Page 2: Installation & Mounting
Installation & Mounting Magnetic Mounting: As with any magnetically-mounted warning device, its use on the exterior of a moving vehicle is at the sole discretion and responsibility of the user. This magnetic mount product provides a secure, temporary installation in most circucumstances and is recom- WARNING! mended for stationary use only. - Page 3 Operation (cont.) Flash Patterns: The CL199 Series LED Beacon is programmed with 30 different flash patterns. Refer the section below for instructions on how to set the flash pattern. Synchronous Flash Patterns FP 1: Single Alert 75 PHASE 1 (Sim)
-
Page 4: Class 1 Ece Wiring Instructions
CL199 ECE R65 Class 1 Version: Wiring Instructions Permanent Mount: The permanent mount beacon wire functions are as outlined below: COLOR FUNCTION CONNECT TO Power +VDC Black Ground Chassis Ground Blue Not Used Yellow Synchronization See Operation Section Purple Not Used Operation Flash Patterns: ECE R65 Single Flash Only... -
Page 5: Class 2 Ece Wiring Instructions
CL199/CL299 ECE R65 Class 2 Version: Wiring Instructions Permanent Mount: The permanent mount beacon wire functions are as outlined below: COLOR FUNCTION CONNECT TO Power +VDC Black Ground Chassis Ground Blue Pattern Switching Chassis Ground to Activate Yellow Synchronization See Operation Section Purple Dimming Chassis Ground to Activate... -
Page 6: Warranty
Manufacturer Limited Warranty Policy: Manufacturer warrants that on the date of purchase this product will conform to Manufacturer’s specifications for this product (which are available from the Manufacturer upon request). This Limited Warranty extends for Sixty (60) months from the date of purchase. DAMAGE TO PARTS OR PRODUCTS RESULTING FROM TAMPERING, ACCIDENT, ABUSE, MISUSE, NEGLIGENCE, UNAPPROVED MODIFICA- TIONS, FIRE OR OTHER HAZARD;...
