Installation & Mounting
Magnetic Mounting:
As with any magnetically-mounted warning device, its use on the exterior of a moving vehicle is at the sole
discretion and responsibility of the user.
This magnetic mount product provides a secure, temporary installation in most circucumstances and is recom-
WARNING!
mended for stationary use only.
The magnetic based beacon provides a secure, temporary installation. The beacon should be placed in the center of the roof
where the least amount of curvature occurs. Check the magnet for debris before installation. Any foreign matter can reduce
holding power and scratch the vehicle. The roof surface should be dry and have a dull, not glossy finish. A glossy, highly
waxed surface will reduce the magnet's holding power. When placed, the beacon should adhere firmly. The user should not
attempt to drive with the beacon in place should the unit slide or move easily.
Permanent Mounting:
The permanent mount beacon provides a secure, permanent installation. Use the supplied foam gasket and screws to mount
the beacon in the desired location. Wire routing should be taken into consideration when choosing a mounting location.
Pipe Mounting (optional):
The beacon base will accept a standard 1" NPT pipe. Hand tighten the beacon base on the pipe thread until the pipe bottoms
out inside the unit.
Voltage Range:
DC 10V~30V
CL199/299 SAE Versions:

Wiring Instructions

Magnetic Mounting:
The magnetic mount beacon is equipped with a light plug with rocker switch, that plugs into a 12 Volt DC cigarette lighter outlet;
rotate and push with reasonable moderate force to insure the best possible connection.
Permanent Mount:
The permanent mount beacon wire functions are as outlined below:
COLOR
Red
Black
Blue
Yellow
Purple
White

Operation

Low Power (Permanent Mount Only):
Connect the Purple wire to Chassis Ground to put the beacon into low power operation. Disable this wire to restore normal,
high power operation.
Upward Facing Patrol LEDs:
On permanent mount beacon, connect the White wire to chassis ground to activate the upward facing Patrol LEDs. Disable
this wire to restore normal operation. Upward facing Partol LEDs are flash pattern dependent on magnetic mount version.
T07890 Rev. A
FUNCTION
Power
Ground
Pattern Switching
Synchronization
Low Power
Upward Facing Patrol LEDs Chassis Ground to Activate
CONNECT TO
+VDC
Chassis Ground
Chassis Ground to Activate
See Operation Section
Chassis Ground to Activate
