Installation, Mounting, & Wiring - Code 3 CELS Installation Manual

Installation Instructions
Mount the System Box using customer supplied screws in the (4) slots provided in the housing's base. Note: This box SHOULD NOT be mounted
on the exterior of the vehicle!
This unit must be mounted within the interior passenger compartment of the vehicle only. It is not intended for use in exterior applica-
tions. All devices should be mounted in accordance with the manufacturer's instructions and securely fastened to vehicle elements of
sufficient strength to withstand the forces applied to the device. Driver and/or passenger air bags (SRS) will affect the way equipment
should be mounted. This device should be mounted by permanent installation and within the zones specified by the vehicle manufac-
turer, if any. Any device mounted in the deployment area of an air bag will damage or reduce the effectiveness of the air bag and may
damage or dislodge the device. Installer must be sure that this device, its mounting hardware and electrical supply wiring does not
WARNING!
interfere with the air bag or the SRS wiring or sensors. Mounting the unit inside the vehicle by a method other than permanent installa-
tion is not recommended as unit may become dislodged during swerving, sudden braking or collision. Failure to follow instructions can
result in personal injury.
WARNING!
Wiring Instructions
See Figure-1 for the wiring harness connection locations of the Control Input Wires and the main power and ground wires. See Figure-2 for the Front
Output Wires, and the Rear Output Wires. Wire the system based on the wiring diagrams for the individual package ordered as shown on pages 6, 7,
8, 9 & 10. The power and ground should be wired using 12 gage wire and 12 gage butt splices with a 20 amp fuse on the power wire. All of the Input
and the Front and Rear Output wires are 22 gage and should be connected with 22 gage butt splices.
Wiring the Individual Dual Color XT4 & PAR36 Light Heads
The CELS Dual Color XT4 & PAR36 Light Heads are "STEADY BURN ONLY" light heads and rely on the CELS Controller for controlling flash pat-
terns. The CELS Dual Color XT4 & PAR36 Light Heads have (3) control wires, (2) Power wires and (1) Ground Wire. The power wire colors match the
colors of the LEDs in the light heads. The Ground wire is always black. NOTE: See wire color chart on page 5 for individual wire colors.
Wiring the Individual Single Color XT4 & PAR36 Light Heads
The CELS Single Color XT4 & PAR36 Light Heads are also "STEADY BURN ONLY" light heads and rely on the CELS Controller for controlling flash
patterns. The CELS Single Color XT4 & PAR36 Light Heads have only (2) control wires, (1) Power wire which is Red and (1) Ground Wire which is
Black.
DO NOT APPLY 12 VOLTS DIRECTLY TO THE CELS BOX OUTPUT WIRES! THE CELS CC BOARD OR
LIGHT HEADS COULD BE DAMAGED BY APPLYING 12 VOLTS TO THE CC OUTPUTS!
WARNING!
Utilizing non-factory supplied screws and/or mounting brackets and/or the improper
number of screws may result in loss of warranty coverage on the equipment.
Figure-1
3
Figure-2
