Summary of Contents for Autel MaxiCheck MX808TS

  • Page 1 All information, specifications and illustrations in this manual are based on the latest information available at the time of printing. Autel reserves the right to make changes at any time without notice. While information of this manual has been carefully checked for accuracy, no guarantee is given for the completeness and correctness of the contents, including but not limited to the product specifications, functions, and illustrations.
  • Page 2: Safety Messages

    Safety Instructions The safety messages herein cover situations Autel is aware of. Autel cannot know, evaluate or advise you as to all of the possible hazards. You must be certain that any condition or service procedure encountered does not jeopardize your personal safety.
  • Page 3 monoxide, an odorless, poisonous gas that causes slower reaction time and can lead to serious personal injury or loss of life. SAFETY WARNINGS  Always perform automotive testing in a safe environment.  Wear safety eye protection that meets ANSI standards. ...
  • Page 4: Table Of Contents

    CONTENTS ......................AFETY NFORMATION ......................AFETY ESSAGES ....................... AFETY NSTRUCTIONS 1 USING THIS MANUAL ....................7 ........................7 ONVENTIONS 2 GENERAL INTRODUCTION ..................8 MX808TS T ..................8 HECK ABLET VCI — V ..............11 EHICLE OMMUNICATION NTERFACE ...................... 13 THER CCESSORIES 3 GETTING STARTED ....................
  • Page 5 7 BATTERY TEST ......................89 BAS BT506 T ....................89 ESTER ......................91 REPARATION ......................92 VEHICLE ......................100 VEHICLE 8 DATA MANAGER ....................... 102 ......................... 102 PERATIONS 9 SETTINGS ........................108 ..........................108 ........................108 ANGUAGE ....................... 109 RINTING ETTINGS ......................
  • Page 6 ....................... 136 OMMUNITIES ......................137 OGGING ........................137 RAINING FAQ ..........................138 17 QUICK LINK ....................... 139 18 FUNCTION VIEWER ....................140 19 DIGITAL INSPECTION ....................142 ..................... 142 DDITIONAL CCESSORIES ..................143 MAGER CCESSORIES ....................144 CCESSORY SSEMBLY ................... 145 ECHNICAL PECIFICATIONS .........................
  • Page 7: Using This Manual

    Using This Manual This manual contains device usage instructions. Some illustrations shown in this manual may contain modules and optional equipment that are not included in your system. Contact your sales representative for availability of other modules and optional tools or accessories. Conventions The following conventions are used.
  • Page 8: General Introduction

    Together with the ability to quickly read and clear DTCs for all available modules of the majority of the makes and models on the market, MaxiCheck MX808TS provides superior special functions, including Oil Reset, EPB (Electronic Parking Brake), SAS (Steering Angle Sensor), BMS (Battery Management System) and DPF (Diesel Particulate Filter).
  • Page 9 Illuminates red when the tablet is powered on and the battery level is below 15%. Collapsible Stand — extends from the back to allow hands-free viewing of the tablet. Figure 2-2 MaxiCheck MX808TS, Back View Heat Sink MaxiVCI Mini Holder...
  • Page 10 Power Sources The tablet can receive power from any of the following sources:  Internal Battery Pack  External Power Supply Internal Battery Pack The tablet can be powered with the internal rechargeable battery, which if fully charged can provide sufficient power for about 7 hours of continuous operation. External Power Supply The tablet can be powered from a wall socket using the USB charging cable and the USB external power adapter.
  • Page 11: Vci - Vehicle Communication Interface

    Item Description Operating Temp. 0 to 50 ° C (32 to 122 ° F) Storage Temp. -10 to 60 ° C (14 to 140 ° F) Operating Humidity 5 % - 95 % non-condensing 270.8 mm (10.0”) x 176.0 mm (6.9”) x 36.0 mm (1.4”) Dimensions ( W x H x D Net Weight...
  • Page 12 Table 2-2 Power LED Color Description Lights solid green when powered on. Green Blinks red when system failure occurs. Power Note: The power LED briefly lights red each time the device powers on and then lights green when the device is ready.
  • Page 13: Other Accessories

    Item Description Dimensions 47 mm (1.7”) x 23 mm (0.9”) x 51 mm (2.0”) (L x W x H) Weight 33.1g (0.07 lb.) Power Sources The MaxiVCI Mini operates on 12-volt vehicle power, which is received through the vehicle’s DLC. The unit powers on whenever it is connected to the vehicle’s DLC. Other Accessories USB Cable (for test) USB Cable (for charging)
  • Page 14: Getting Started

    The power LED light will illuminate green. The system boots up and displays the lock screen. Slide the Lock icon to the left to enter the MaxiCheck Job Menu or slide to the right to unlock. Figure 3-1 Sample MaxiCheck MX808TS Job Menu Application Buttons Locator and Navigation Buttons...
  • Page 15 Application Buttons Descriptions of the tool applications are displayed in the table below. Table 3-1 Applications Button Name Description Accesses diagnostics functions menu. See Diagnostics Diagnostics details. Service Accesses special functions menu. See Service for details. TPMS Accesses the TPMS service program. See TPMS for details.
  • Page 16 Button Name Description Launches the Support platform which synchronizes Autel’s on- Support line service base station with the MaxiCheck tablet. See Support for details. Provides associated website bookmarks to allow quick access Quick Link to product update, service, support and other information. See Quick Link for details.
  • Page 17: Powering Down

    Button Name Description Opens the VCI Manager application. The check at the bottom right corner indicates tablet communicating with the MaxiVCI Mini. An X will display if the tablet is not connected to VCI. TPMS Shortcut Returns to the TPMS screen. Diagnostics Returns to the Diagnostics screen.
  • Page 18  To power down the tablet Long press the Lock/Power Button. Tap Power off option. Tap OK, the tablet will turn off in a few seconds. Reboot System In case of system crash, long press the Lock/Power button and tap Reboot option to reboot the system.
  • Page 19: Diagnostics

    Diagnostics The Diagnostics application can retrieve ECU information, read & erase DTCs, and view live data. The Diagnostics application can access the electronic control unit (ECU) for various vehicle control systems, including engine, transmission, antilock brake system (ABS), airbag system (SRS). Establishing Vehicle Communication The Diagnostics operations require connecting the MX808TS Diagnostics Platform to the test vehicle through the MaxiVCI Mini.
  • Page 20 Bluetooth Connection Bluetooth pairing is recommended as the first choice for the communication between the tablet and the MaxiVCI Mini. The working range for Bluetooth communication is about 33 feet (about 10 m), enabling remote vehicle diagnostics. More than one MaxiVCI Mini to connect to the test vehicles, you can perform vehicle diagnosis on various vehicles conveniently by pairing the tablet separately to each of the MaxiVCI Mini devices connected to the different test vehicles via wireless BT.
  • Page 21: Getting Started

    technical support for help. If the MaxiVCI Mini is unable to establish a communication link, a prompt message displays with check instructions. The following conditions are the possible causes:  The MaxiVCI Mini is unable to establish a communication link with the vehicle. ...
  • Page 22: Vehicle Identification

    Top Toolbar Buttons The operations of the toolbar buttons at the top of the screen are listed and described in the table below: Table 4-1 Top Toolbar Buttons Button Name Description Home Returns to the MaxiCheck Job Menu. Provides a fast way to identify the test vehicle. See VIN Scan Vehicle Identification for details.
  • Page 23  To perform Auto VIN Scan Tap the Diagnostics application button from the MaxiCheck Job Menu. The Vehicle Menu displays. Tap the VIN Scan button on the top toolbar to open the dropdown list. Figure 4-2 Sample Auto VIN Screen Select Auto Detect.
  • Page 24 Figure 4-4 Sample Vehicle Profile Screen The tool establishes communication with the vehicle and reads the control unit information. Choose Auto Scan to scan all the test vehicles’ available systems or tap Control Unit to access a specific system to diagnose. Figure 4-5 Sample Diagnostic Screen Manual VIN Input For vehicles not supporting the Auto VIN Scan function, you may manually enter the...
  • Page 25 Figure 4-6 Sample Diagnostic Screen Tap Done. Once the vehicle is identified, the Vehicle Diagnostics screen displays. Tap Cancel to exit Manual Input. Automatic Selection The Auto VIN Scan can be selected after selecting the test vehicle manufacturer. Figure 4-7 Sample Selection Screen ...
  • Page 26: Navigation

    Manual Selection When the vehicle’s VIN is not automatically retrievable through the vehicle's ECU, or the specific VIN is unknown, the vehicle can be manually selected. This mode of vehicle selection is menu driven, repeat the first two steps from the automatic selection operation and tap Manual Selection.
  • Page 27 Diagnostics Toolbar The Diagnostics Toolbar contains a number of buttons such as print and save. The table below provides a brief description of the operations of the Diagnostics Toolbar buttons. Table 4-2 Diagnostics Toolbar Buttons Button Name Description Home Returns to the MaxiCheck Job Menu. Exits the service session of the currently identified test Vehicle Swap...
  • Page 28 shot copy of the current screen. A temporary file will be created and sent to the connected PC for printing. When the file is transferred successfully, a confirmation message displays.  To submit Data Logging reports in Diagnostics Tap the Diagnostics application button from the MaxiCheck Job Menu. The Data Logging button on the diagnostics toolbar is available throughout the Diagnostics operations.
  • Page 29: Diagnosis

    Warning Messages This type of messages displays a warning that a selected action may result in an irreversible change or loss of data. An example of this type of message is the “Erase Codes” message. Error Messages Error messages display when a system or procedural error has occurred. Examples of possible errors include a disconnection or communication interruption.
  • Page 30 Auto Scan The Auto Scan function performs a comprehensive scanning over all the ECUs in the vehicle’s ECU to locate systems faults and retrieve DTCs. An example of Auto Scan interface is pictured as below: Figure 4-9 Sample Auto Scan Operation Screen Navigation Bar Main Section Function Buttons...
  • Page 31 Function Buttons A brief description of the Auto Scan’s Function Buttons’ operations are displayed in the table below. Table 4-3 Function Buttons Name Description Report Displays the diagnostic data in the report form. Deletes codes. A warning message screen will display to inform you Quick of possible data loss when this function is selected.
  • Page 32 Control Unit Manually locate a required control system for testing through a series of choices. Follow the menu driven procedures and make proper selections; the application guides the user to the proper diagnostic function menu based on selections. Figure 4-10 Sample Function Menu The Function Menu options vary slightly for different vehicles and may include: ECU Information —...
  • Page 33 ECU Information This function retrieves and displays the specific information for the tested control unit, including unit type, version numbers and other specifications. The sample ECU Information screen displays as below: Figure 4-11 Sample ECU Information Screen Diagnostics Toolbar Buttons — see Table 4-2 Diagnostics Toolbar Buttons detailed descriptions of the operations for each button.
  • Page 34 Main Section Code Column — displays the retrieved codes from the vehicle.  Status Column — indicates the status of the retrieved codes.  Description Column — detailed descriptions for the retrieved codes.  Snowflake Icon — only displays when freeze frame data is available for viewing; ...
  • Page 35 Live Data When this function is selected, the screen displays the data list for the selected module. The items available for any control module vary by vehicle. The parameters display in the order that they are transmitted by the ECM, so expect variation between vehicles. Gesture scrolling allows for quick movement through data list.
  • Page 36 Text Mode — this is the default mode which displays the parameters text, displaying in list format. NOTE Status parameters, such as a switch reading, can primarily be viewed in text form such as ON, OFF, ACTIVE, and ABORT. Whereas, value parameter, such as a sensor reading, can be displayed in text mode and additional graph modes.
  • Page 37 be triggered automatically at preset threshold value or values may be set manually. The triggering mode and record duration can be configured in the Setting mode of Live Data. Freeze — displays the retrieved data in freeze frame mode. Previous Frame — displays previous frame of the freeze data. ...
  • Page 38 beep sound as a reminder whenever the data reading reaches the preset minimum or maximum point.  To set threshold limits for the parameter values Tap the Setting function button at the bottom of the Live Data screen. Tap the Selected navigation button. Select a parameter item on the left column, or enter the item name in the Search bar.
  • Page 39 Tap Done to save the setting and return to the Live Data screen; or tap Cancel to cancel without saving and exit Setting.  Done Button - confirms and saves the setting, and returns to the Live Data screen. Cancel Button — cancels the setting operation, and returns to the Live Data screen. ...
  • Page 40: Generic Obdii Operations

    Special Functions These functions perform various component adaptations, allowing you to recalibrate or configure certain components after making repairs or replacement. The main menu displays the supported special functions for the test vehicle. Follow the on-screen instructions to complete the desired function. When the operation is done, an execution status message such as Completed, Finished or Successful, displays.
  • Page 41 from which the vehicle is broadcasting. Protocol — when this option is selected, the screen opens a sub menu  listing various protocols. A communication protocol is a standardized way of data communication between an ECM and a diagnostic tool. Global OBD may use several different communication protocols.
  • Page 42 Function Descriptions This section describes the various functions of each diagnostic option: DTC & FFD When this function is selected, the screen displays a list of Stored and Pending Codes. A snowflake button will display on the right side of the DTC item when the Freeze Frame data is available for viewing.
  • Page 43  Freeze Frame Typically, the stored frame is the last DTC that occurred. Certain DTCs that have a greater impact on vehicle emission, have a higher priority. In these cases, the top prioritized DTC is the one for which the freeze frame records are retained. Freeze data includes a “snapshot”...
  • Page 44: Exiting Diagnostics

    Vehicle Status This option is used to check the current condition of the vehicle, including communication protocols of OBDII modules, retrieved codes amount, status of the Malfunction Indicator Light (MIL), and other additional information. Exiting Diagnostics The Diagnostics application remains open as long as there is an active communication with the vehicle.
  • Page 45: Service

    Service The Service section is specially designed to provide quick access to the vehicle systems for various scheduled service and maintenance tasks. The typical service operation screen is a series of menu driven executive commands. Follow on-screen instructions to select appropriate execution options, enter correct values or data, and perform necessary actions.
  • Page 46 NOTE For some vehicles, the scan tool can reset additional service lights such as maintenance cycle and service interval. Take BMW vehicles as an example, service resets include engine oil, spark plugs, front/rear brakes, coolant, particle filter, brake fluid, micro filter, vehicle inspection, exhaust emission inspection and vehicle check.
  • Page 47 Figure 5-3 Sample Oil Reset Service Screen 1 The available items will display in a table of three columns: CBS value, availability, and service counter. Figure 5-2 Sample Oil Reset Service Screen 2 Tap on the value and then tap the Reset button on the right bottom of the screen. When the reset is done, the availability would display as 100%.
  • Page 48: Electronic Parking Brake (Epb) Service

    Ensure that the EPB control system is reactivated after the maintenance work has been completed. NOTE Autel accepts no responsibility for any accident or injury arising from the maintenance of the Electronic Parking Brake system.  To perform EPB functions Tap the Service application button from the MaxiCheck Job Menu.
  • Page 49 Press OK button to exit. EMF Start-up This service function would start up the parking brake. It must be conducted after the following repairs: Figure 5-6 Sample EMF Start-up Screen 1  Replacing an EMF control unit.  Replacing the parking brake button. Tap Continue to proceed with this service function or the Back button at the bottom left to exit.
  • Page 50: Battery Management System (Bms) Service

    The following screen will display a message to advise that the fault memory of the parking brake control unit will be deleted. Press Continue to proceed or the Back button on the bottom navigation bar to exit. Figure 5-8 Sample EMF Start-up Screen 3 Follow the on-screen instructions to pull the parking brake button and wait for approximately three seconds until the parking brake is set.
  • Page 51 the on-screen instructions to make correct option selection. The vehicle may use either a sealed lead-acid battery or an AGM (Absorbed Glass Mat) battery. Lead acid battery contains liquid sulphuric acid and can spill when overturned. AGM battery (known as VRLA battery, valve regulated lead acid) also contains sulphuric acid, but the acid is contained in glass mats between terminal plates.
  • Page 52 Tap on the desired service. In this example, choose function one: Display kilometer reading at last battery change and one before last. A notice screen displays. Figure 5-9 Sample BMS Function List Read carefully the complete information and press Continue. Figure 5-10 Sample BMS Screen 1 Check the battery capacity and the battery replacement information on the screen.
  • Page 53 Tap on the corresponding function (function 1 in our example) to return to the selection screen or press the function 2 to end the service function. Figure 5-12 Sample BMS Screen 3  To register the battery replacement Tap on the appropriate step to complete. In our example, tap function 2 Register battery replacement.
  • Page 54 Figure 5-14 Sample BMS Screen 5 Select function 1 for example: Read carefully the information on the screen and tap Yes to continue. Figure 5-15 Sample BMS Screen 6 Follow the on-screen instructions to input the data matrix code of the newly installed battery that should be on the label of the battery.
  • Page 55: Steering Angle Sensor (Sas) Service

    Accident repairs where damage to the steering angle sensor or assembly, or any part of the steering system may have occurred NOTE AUTEL accepts no responsibility for any accident or injury arising from servicing the SAS system. When interpreting DTCs retrieved from the vehicle, always follow the manufacturer’s recommendation for repair.
  • Page 56 Use Land Rover as an example. Tap the Service application button from the MaxiCheck Job Menu. Tap SAS button and wait for the vehicle manufacturer screen. You can tap VIN Scan or the vehicle make to acquire vehicle VIN information and tap Yes to confirm. See Vehicle Identification for detail.
  • Page 57: Diesel Particle Filter (Dpf) Service

    Ensure the steering wheel is in the central position and the front wheels are in the straight position. Then tap OK to proceed. Figure 5-19 Sample SAS Function Screen 2 When the operation is completed, the scan tool will display a confirmation message. An error message will display if the procedure cannot be completed.
  • Page 58 NOTE The DPF will not regenerate if the engine management light is on, or there is a faulty EGR valve. The ECU must be re-adapted when replacing the DPF and when topping up the fuel additive Eolys. If the vehicle needs to be driven in order to perform a DPF service, a second person is needed for the function.
  • Page 59 [1] Enter New Value for Adjustment From the Starting Basic Inspection Quantity menu, tap [1] and the screen displays as below. Figure 5-22 Sample Enter New Value Screen After entering the value, tap OK to save the value to the tool. Tap ESC to exit the operation.
  • Page 60 Figure 5-23 Sample Injection Rate Screen [1] Enter New Value for Matching From the Injection Rate menu, tap [1] and the screen displays as below. Figure 5-24 Sample Enter Value Screen NOTE The data you input should be in given range. If the input data is out of range, the tool will display a warning message “Permissible adjustment range exceeded.”...
  • Page 61 Tap the corresponding number button to enter new value for each cylinder. Follow the on-screen instructions to tap on the corresponding number [1] [2] [3] [4] to enter the new value for the cylinder, restore the old value, and exit after finish the function.
  • Page 62 When the particle filter regeneration is complete, confirm to exit the display. Tap Repeat to recheck the status again or tap End to exit. Figure 5-27 Sample Repeat Screen NOTE In the case of a particle filter heavily loaded with soot, it can occur that the regeneration request is blocked again after a short time or is not released.
  • Page 63: Immobilizer (Immo) Service

    Figure 5-28 Sample Codes Screen The tool shows a list of particle filter test. Select the corresponding number button to perform the desired test [1] [2] [3] [4] [5]. [1] Visual Inspection of Engine Oil [2] Visual Inspection of Particulate Filter [3] Function Check or Swirl Flaps [4] Exhaust Backpressure Test [5] Actual/Target Value Check-Mass Air Flow Sensor...
  • Page 64  To program the replacement key fob(s) Tap IMMO KEYS after entering the Service function from the MaxiCheck Job Menu. Tap Automatic Selection or Manual Selection to acquire vehicle VIN information and tap Yes to confirm. Tap Erase/Program all key fobs in the IMMO function list once displayed. The list may vary by test vehicles.
  • Page 65: Tpms

    TPMS MX808TS provides the most comprehensive TPMS services for technicians to quickly solve TPMS related problems in the shortest time and with the highest efficiency. Getting Started TPMS Service Menu Layout Figure 6-1 Sample TPMS Vehicle Menu Screen Tap TPMS on the MaxiCheck Job Menu to access the TPMS Vehicle Menu. Top Toolbar Buttons —...
  • Page 66 Table 6-1 Top Toolbar Buttons on Vehicle Menu Button Name Description Home Returns to the MaxiCheck Job Menu. Identifies vehicle make, model and year by retrieving Vehicle Identification Number (VIN) from the test vehicle. See Vehicle Scan Identification. Displays the stored test vehicle history records. See History Vehicle History.
  • Page 67: Vehicle Selection

    Vehicle Selection The VIN Scan function is used to quickly identify the test vehicle, refer to Auto VIN Scan for details. Figure 6-2 Sample Vehicle Manufacturer Selection Or, select a manufacturer brand on the TPMS Service Menu and follow the on-screen instructions to select the vehicle make, model and year.
  • Page 68 Figure 6-4 Sample Vehicle Year Selection 1 The following screen may display for vehicles using Indirect TPMS. Figure 6-5 Sample Indirect TPMS Selection Screen For Indirect TPMS vehicle, only the Relearn function is supported. Tap the vehicle year information button, in the case of the above screen – 2008/08-2017/01 (indirect), to display the Relearn Procedure, follow the instructions to complete the operation.
  • Page 69 For vehicles using Direct TPMS, select the correct vehicle. The TPMS service menu will display next. Figure 6-7 Sample Check Screen 1 Top Toolbar Buttons — refer to Table 4-2 Diagnostics Toolbar Buttons for details. Navigation Tab Main Section Function Buttons Navigation Tab The navigation tab at the top of the Main Section screen contains the following items: Check Tab —...
  • Page 70: Tpms Check

    Function Buttons Specific Function Buttons will display depending on operation. These buttons or icons can be used to trigger the TPMS sensor, create sensor IDs, program MX-Sensors and return to the previous screen or exit. TPMS Check The Check function allows user to activate TPMS sensor to view sensor data - sensor ID, tire pressure, tire temperature, battery condition and sensor position.
  • Page 71: Tpms Diagnosis

    Table 6-2 Possible Results for Triggering Icon Results Description TPMS sensor is successfully activated and decoded. The table displays the sensor Successful Sensor Read information. (Green) TPMS sensor is successfully activated and Successful Sensor Read & (Green) decoded and the battery level of the sensor Low Battery is low.
  • Page 72 To connect the MaxiVCI Mini to the test vehicle, insert the Vehicle Data Connector on the MaxiVCI Mini into the vehicle’s DLC which is generally located under the vehicle dash and the MaxiVCI Mini will be automatically powered on. NOTE The vehicle’s DLC is not always located under the dash;...
  • Page 73 if the right MaxiVCI Mini has been paired up with the tablet.  If communication is lost during diagnosis, ensure there is no nearby object that might cause signal interruption.  Stand closer to the MaxiVCI Mini to obtain a stronger signal, and a faster communication speed.
  • Page 74 If the OBD function is supported by the test vehicle, the sensor ID saved in the TPMS ECU will be retrieved and displayed on the screen with an OBD icon adjacent to it. If the sensor ID retrieved from sensor activation is the same as the ID saved in the ECU, the trigger mark ( ) and OBD mark ( ) will display green.
  • Page 75 In this screen, the detailed fault definition will display. Select one of the DTC and tap Search, the tablet will automatically connect to the Internet and additional information will display. Figure 6-12 Sample DTCs Screen If no DTCs are present in the TPMS ECU, a green “No DTC” message will display on the DTC screen.
  • Page 76: Sensor Programming

    For more details, please refer to Live Data. Figure 6-14 Sample Live Data Screen Special Functions Tap this button to display a menu of available special functions. Tap button to initiate desired vehicle lamp function test. Figure 6-15 Sample Special Functions Screen Sensor Programming The Programming function allows users to program the sensor data to the MX-Sensor to replace existing sensors with low battery life and ones that are no longer functioning.
  • Page 77 This device offers four programming methods when programming MX-Sensor: Copy by Activation, Copy by OBD, Copy by Input and Auto Create. Figure 6-16 Sample Programming Screen 1 The sensor IDs retrieved from sensor activation and TPMS ECU will display on the left column of the table with the appropriate signal or OBD icon.
  • Page 78 A window will display for your confirmation. Tap OK to program, or tap Cancel to quit the operation. Figure 6-18 Sample Copy by Activation Confirmation Screen Figure 6-19 Sample Copy by Activation Screen When the programming is complete, the programmed ID will display in the column to the right of the wheel designation.
  • Page 79 By using Copy by Activation, the sensor ID that is retrieved from activated sensor is programmed to the new MX-Sensor. Because the IDs of the original sensor and the new MX-Sensor are the same and the ID is already recognized to the vehicle ECU, there is no need to perform the Relearn function when the new programmed sensor has been attached to the same wheel.
  • Page 80 Select a wheel location on the display and place a MX-Sensor near the top right corner of the tablet and then tap Copy by Input to program the new MX-Sensor. Figure 6-22 Sample Copy by Input Screen Tap Copy by Input. When the input box displays, enter the ID of the original sensor. Tap inside the input box to display a soft keyboard.
  • Page 81: Tpms Relearn

    Select the vehicle model, select a wheel location on the display and place a MX-Sensor near the top right corner of the tablet. Tap Auto Create to program the new MX-Sensor. Figure 6-23 Sample Auto Create Screen A random ID will be created for the MX-Sensor. This new ID differs from the ID stored in the TPMS ECU, therefore the sensor will have to be relearned to the TPMS ECU.
  • Page 82 Then follow the Relearn Procedure to perform Stationary Relearn. Figure 6-24 Sample Stationary Relearn Screen 1 Figure 6-25 Sample Stationary Relearn Screen 2...
  • Page 83 Automatic Relearn For some vehicles, the Relearn function can be completed by driving. Refer to the on- screen Relearn Procedure for the exact details of the process. Figure 6-26 Sample Automatic Relearn Screen 1 Figure 6-27 Sample Automatic Relearn Screen 2 OBDII Relearn OBDII Relearn The OBDII Relearn function allows the MX808TS tablet to directly write the TPMS sensor...
  • Page 84 To perform the Relearn, activate all four sensors. Figure 6-28 Sample OBDII Relearn Screen 1 Figure 6-29 Sample OBDII Relearn Screen 2...
  • Page 85: Tpms By Oem Part No

    OBDII-Assisted Relearn The MX808TS also can perform an OBDII-Assisted Relearn. Some vehicles relearn procedure require that a tool be connected to the vehicle while another tool be used to trigger the sensor at the wheel. Since the MX808TS tablet wirelessly communicates with vehicles, it can be used to trigger wheel-mounted sensors while still being connected with the vehicle eliminating the need for a second tool.
  • Page 86 Function Operations Tap OEM Part No. on the TPMS service menu to access the next screen. A list of sensor OEM part numbers will display. Swipe the screen left and right to find the correct OEM part number of the sensor on the test vehicle. Figure 6-30 Sample OEM Part No.
  • Page 87 When a specific OEM part No. is selected, the screen will display as pictured below. Figure 6-32 Sample OEM Part No. Service Menu NOTE Only sensor Check and Programming functions are available with the OEM Part No. function. The Diagnosis and Relearn functions can only be accessed by selecting a vehicle on the TPMS service menu.
  • Page 88 There are three options available when programming MX-Sensor using the OEM Part No. function: Copy by Activation, Copy by Input, and Auto Create. Refer to Sensor Programming. Figure 6-34 Sample Programming Screen via OEM Part No. NOTE Auto Create in this section can program up to 20 MX-Sensors at a time. The PSN Code (Part Serial Number), which is printed on the MX-Sensor, acts as a reference to identify the corresponding sensor ID.
  • Page 89: Battery Test

    Battery Test The MaxiBAS BT506 is a battery and electrical system analysis tool that uses Adaptive Conductance, an advanced battery analysis method to produce a more accurate examination of the battery’s cold cranking ability and reserve capacity, which is vital to determine a battery’s true health.
  • Page 90 Table 7-1 LED Description Color Description The tester is communicating via USB cable. Flashing Green Status Flashing Blue The tester is communicating via Bluetooth. Battery clamps are connected to the wrong battery Flashing Red terminals. The tester is powered on and the battery is sufficiently Solid Green charged.
  • Page 91: Test Preparation

     To pair the BT506 with the MaxiCheck tablet Press and hold the Lock/Power Button to turn on both MaxiCheck MX808TS tablet and BT506. Ensure that the units are sufficiently charged before use. Enable Bluetooth on the MaxiCheck MX808TS tablet by tapping VCI Manager >...
  • Page 92: In-Vehicle Test

    Check the serial number of your BT506 tester and select the desired device for pairing. When paired successfully, the connection status will read as “Connected” and the Status LED will flash blue. Figure 7-2 Connecting with the Tablet To connect to a battery Connect the red clamp to the positive (+) terminal and the black clamp to the negative (-) terminal of the battery.
  • Page 93 sequence.  Confirm Vehicle Information Tap In-vehicle Test. Figure 7-4 Sample Battery Test Screen Confirm your vehicle information and make sure the VIN information is filled. Figure 7-5 Sample Vehicle Information Screen Confirm your battery information, including voltage, type, standard, and capacity. Tap Next to continue.
  • Page 94 Table 7-3 Top Toolbar Buttons Button Name Description The value on the icon indicates the real-time voltage of Battery the tested battery. In the battery test, the button will turn Connection green if the battery is good; otherwise, it will turn red. Home Returns to the MaxiCheck Job Menu.
  • Page 95 Battery Test Follow the on-screen instructions. Check the boxes once all required tasks are completed, and tap Start Testing. Figure 7-6 Sample Battery Screen Wait until the test is completed. The test results will be displayed on the tool. Figure 7-7 Sample Battery Test Results Screen...
  • Page 96 Battery Test Results The battery test results include a color-coded results summary, a list of test data, and repair tips. Table 7-4 Test Results Result Repair Tip Good Battery Battery is good. Good & Recharge Battery is good but insufficiently charged. Recharge the battery. Charge &...
  • Page 97 Starter Test Follow the on-screen instructions to complete the test. Start the engine and let it idle. The test results will appear as follows: Figure 7-8 Sample Starter Screen Figure 7-9 Sample Starter Test Results Screen...
  • Page 98 Table 7-5 Starter Test Results Result Description Cranking Normal The starter is good. Current Too Low Low momentary discharge capacity. Voltage Too Low Low battery storage capacity. Not Started The starter is not detected for starting.
  • Page 99 Generator Test Follow the on-screen instructions to complete the test. The test results will appear as follows: Figure 7-10 Sample Generator Test Results Screen Table 7-6 Generator Test Results Result Description Charging Normal The generator is functioning normally.  The belt linking the starter and the generator is loose;...
  • Page 100: Out-Vehicle Test

    Out-vehicle Test Out-vehicle Test is used to test the conditions of batteries that are not connected to a vehicle. This function aims to check the health status of the battery only. Test Procedure  To start the out-vehicle test Tap Out-vehicle Test. Connect the tester clamps to the battery terminals.
  • Page 101 Test Results Icons are color-coded to indicate status. Table 7-7 Out-vehicle Test Results Result Description Good Battery Battery meets required standards. Battery is good, but low on charge. Fully charge the Good & Recharge battery. Check for causes of low charge. Charge &...
  • Page 102: Data Manager

    Data Manager The Data Manager application is used to store, print, and review the saved files. Most operations are controlled through the toolbar. Selecting the Data Manager application opens the file system menu. Different file types are sorted separately under different options, there are seven types of information files to be viewed or played back.
  • Page 103 Figure 8-2 Sample Image Screen Toolbar Buttons — used to edit, print and delete the image files. See the following table for detailed information. Main Section — displays the stored images. Table 8-1 Toolbar Buttons in Image Screen Button Name Description Back Returns to the previous screen.
  • Page 104 Tap the Info button to display image information. Tap the Edit button on the top right corner of the window. The editing screen displays. Edit the image information by entering the new file name, and file information. Tap Done to save the information and exit, or tap Cancel to exit without saving. ...
  • Page 105 Figure 8-4 Sharing Report Screen 1 Tap View local reports to display it in full screen. Return to the Report List screen, tap the report and tap Report cloud sharing. Figure 8-5 Sharing Report Screen 2 Scan the QR code or tap Send Email or Send SMS to share the report. The PDF section stores and displays all saved data PDF files.
  • Page 106 On the Review Data main screen, select a record file to playback. Figure 8-6 Sample Data Playback Screen Drop-down Toolbar — tap the button at the top center of the screen to open the Drop-down Toolbar. Main Section — displays the recorded data frames. Navigation Toolbar —...
  • Page 107 Figure 8-7 Sample Vehicle Management Screen Data Logging The Data Logging section allows you to launch Support platform directly to view all records of all sent or unsent (saved) data loggings on the diagnostics system. For more details, please refer to Data Logging.
  • Page 108: Settings

    Settings Tap the Settings button to adjust the default setting and view information about the MaxiCheck system. The following shows the options available for the MaxiCheck system settings:  Unit  Language  Printing Settings  Report Settings  Multitask ...
  • Page 109: Printing Settings

     To install the printer driver program to a PC Download the Maxi PC Suite from www.autel.com > Support > Downloads > Diagnostic Tool and install to your PC. Double click the setup.exe file.
  • Page 110: Multitask

    to enable/disable the Report Upload to Cloud function. The button appears blue if the function is enabled and is gray if the function is disabled. Multitask The Multitask option allows you to turn the Multitask function on or off. The Multitask feature enables you to browse and navigate more freely among different applications on the MaxiCheck system.
  • Page 111: Car Order

    NOTE The tool must be connected to the Internet at the time download is scheduled. Car Order This option allows you to sort the vehicles either by alphabetical order or by frequency of use.  To adjust the vehicle list setting Tap Settings on the MaxiCheck Job Menu.
  • Page 112 Tap the About option on the left column. The product information screen displays on the right. Tap the Home button on the top left corner to return to the MaxiCheck Job Menu or select another setting to adjust.
  • Page 113: Update

    Update This chapter describes the update operation for both the MX808TS tablet and the MaxiVCI Mini. The software and firmware updates of the tablet can be completed on the tablet via Internet, while the updates for MaxiVCI Mini can be completed either via the connection with the tablet or via the connection with a PC.
  • Page 114 Search Bar — search specific update item by inputting the file name, for  example: enter a vehicle manufacturer. Status Bar Left Side — displays your account email address and expiration date of your  subscription. Right Side — shows the remaining days of your subscription and real-time ...
  • Page 115: Maxivci Mini Update

    Update via PC  To update the MaxiVCI Mini via PC Download the Maxi PC Suite from www.autel.com > Support > Downloads > Diagnostic Tools, and install it onto your windows-PC. Connect the MaxiVCI Mini to a PC using a USB cable.
  • Page 116: Vci Manager

    VCI Manager This application pairs the tablet with the MaxiVCI Mini, checks the communication status and update the VCI software and TPMS service firmware. Figure 11-1 Sample VCI Manager Screen ① Connection Mode — there are four connection modes available for selection. The connection state is displayed alongside.
  • Page 117 NOTE A VCI can be paired with only one tablet at a time, and once it's been paired, the device will not be discovered by any other unit.  BAS BT — when paired to a battery tester via Bluetooth, the connection state displays as Connected;...
  • Page 118: Shop Manager

    Shop Manager The Shop Manager application manages the workshop information, customer information records, and test vehicle history records. There are three main functions available:  Vehicle History  Workshop Information  Customer Manager The operations of these functions of the Shop Manager application are mainly manipulated by the toolbar buttons, which are listed and described in the table below: Table 12-1 Top Toolbar Buttons in Shop Manager Button...
  • Page 119: Vehicle History

    Vehicle History This function stores test vehicle history records, including vehicle information and the retrieved DTCs from previous diagnostics sessions. All information is displayed in summarized details. Tap on a record to resume a diagnostics session on a “stored vehicle”. Figure 12-1 Sample Vehicle History Screen ...
  • Page 120: Workshop Information

    Figure 12-2 Sample Historical Test Record Sheet  To edit the Historical Test record sheet Tap the Shop Manager application on the MaxiCheck Job Menu. Tap Vehicle History. Select the specific vehicle history record thumbnail from the main section. The Historical Test record sheet displays.
  • Page 121: Customer Manager

    Figure 12-3 Sample Workshop Information Sheet  To edit the Workshop Information sheet Tap the Shop Manager application on the MaxiCheck Job Menu. Tap Workshop Information. Tap the Edit button on the top toolbar. Tap on each field to input the appropriate information. Tap Done to save the updated workshop information sheet, or tap Cancel to exit without saving.
  • Page 122  To edit a customer account Tap the Shop Manager application on the MaxiCheck Job Menu. Tap Customer Manager. Select a customer account by tapping the corresponding name card. A Customer Information sheet displays. Tap the Edit button on the top toolbar to start editing. Tap on the input field where needs to be altered or supplemented, and enter updated information.
  • Page 123: Academy

    Academy Autel provides various tutorial articles and technical bulletins produced by top-notch technicians and product experts. Please view the materials that are saved on the tablet or view technical articles from our online forum by clicking the links displayed under this...
  • Page 124: Remote Desk

    You can use the application to receive ad-hoc remote support from Autel’s support center, colleagues, or friends, by allowing them to control your MaxiCheck tablet on their PC via the TeamViewer software.
  • Page 125 Tap Allow to accept, or tap Deny to reject. Refer to the associated TeamViewer documents for additional information.
  • Page 126: Maxifix

    MaxiFix The MaxiFix application launches the on-line troubleshooter database, which not only provides you virtually all common diagnostics trouble code (DTC) database for most vehicles, but also serves as a forum allowing you to network with other MaxiCheck users, and gives you access to a vast database of repair and diagnostics tips along with proven filed fixes.
  • Page 127 The Header The Header at the top of the screen features:  A Select Vehicle button to open the vehicle identification window, and vehicle information bar, for example “2014 > Hyundai > Accord Coupe > L4-2.4L (K24W1)”.  A search field to find relevant information by entering keywords, codes, or problems. Select Vehicle Button The Select Vehicle button on the Header allows you to specify the vehicle which you want to research on MaxiFix, by selecting each of the vehicle attribute from a sequence...
  • Page 128: Operations

    Select the model of the vehicle from the list. Select the submodel of the vehicle from the list. Select the engine of the vehicle from the list. After completing the vehicle selection procedure, the identified vehicle is shown on the Header. Enter a Search Term.
  • Page 129  My MaxiFix — shows all your posts including Questions and Fixes in the community, and allows you to view your personal profile, select your vehicle preference, and share your tips.  My Messages — shows a list of message notifications which is relevant to your activities in the Question section.
  • Page 130 Marked Posts — opens a list with links to Tips and discussions that you are actively  participating in. My Profile — allows you to view your Autel account information including: your Autel  ID, personal information, MaxiFix score, phone number and register time, and edit your portrait.
  • Page 131 Create a Tip A “Tip” is a concise and complete description of the fix for a particular vehicle repair issue.  To create a new MaxiFix Tip Select My MaxiFix from the Navigation Menu. Select Select Vehicle from the Header and enter the identifying attributes of the vehicle you are writing the Tip about.
  • Page 132 close the question. If your answer is marked as “Adopted!”, the prompt “Adopted! + 4” will be displayed permanently. Tap Clear to delete all message notifications. Select “Adopted Answers” Members are requested to select one Adopted Answer from all of the responses on “My Messages”...
  • Page 133 If you wish to contact the administrator of MaxiFix site, please use the contact form. Select Support from the Navigation Menu to open the comment window. To allow the administrator to respond to your question or issue, the following information should be provided: ...
  • Page 134: Support

    If you already have an Autel account, sign in with your account ID and password, and skip to step 9. If you are a new member to Autel, click Register on the left side of the screen to create your Autel ID.
  • Page 135: Support Screen Layout

    The User Info and Device Info are both included under the Personal Info section.  User Info - displays detailed information of your registered on-line Autel account, such as your Autel ID, Name, Address and other contact information, etc. Device Info — displays the registered product information, including the Serial ...
  • Page 136: Communities

    Communities The Communities section launches and synchronizes with the Technical Forums on Autel’s official website www.autel.com, where you are allowed to discuss technical topics or share information with, as well as ask for technical advices or offer technical supports to all other members in Autel’s online support communities.
  • Page 137: Data Logging

    The Training section provides quick links to Autel’s online video accounts. Select a video channel by the language to see all the available online tutorial videos from Autel for various technical supports, such as product usage techniques and vehicle diagnostics...
  • Page 138: Faq

    The FAQ section provides you comprehensive references for questions frequently asked and answered about the use of Autel’s online member account, and shopping and payment procedures. Account — displays questions and answers about the use of Autel’s online user ...
  • Page 139: Quick Link

    Quick Link The Quick Link application provides convenient access to Autel’s official website and to additional in automotive service sites. Figure 17-1 Sample Quick Link Screen  To open a quick link Tap the Quick Link application on the MaxiCheck Job Menu. The Quick Link application screen displays.
  • Page 140: Function Viewer

    Function Viewer The Function Viewer allows you to search the functions supported by our tools and the software version information. There are two ways of searching, either by searching the tool and the vehicle or searching the functions.  To Search by the vehicle Tap the Function Viewer application on the MaxiCheck Job Menu.
  • Page 141  Search by the functions Tap the Function Viewer application on the MaxiCheck Job Menu. The Function Viewer application screen displays. Tap the tool name on the top left to drop down the tool list, tap the one you want to search.
  • Page 142: Digital Inspection

    Digital Inspection The Digital Inspection application configures the MaxiCheck Diagnostics Device to operate as a digital video scope by simply connecting the tablet to an Inspection Camera. This function allows you to examine difficult-to-reach areas normally hidden from sight, with the ability to record digital still images and videos, which offers you an economical solution to inspect machinery, facilities, and infrastructure in a safe and quick way.
  • Page 143: Imager Head Accessories

    Inspection Camera Figure 19-1 Inspection Camera ① Removable Imager Head Cable — connects to the tool when performing inspections for image and video viewing. ② Handgrip — ergonomically designed handle for comfortable grip and agile operation. ③ USB Cable — connects the Inspection Camera to the MaxiCheck tablet. Imager Head Accessories Figure 19-2 8.5 mm Imager Head Accessories ①...
  • Page 144: Accessory Assembly

    Figure 19-3 5.5 mm Imager Head Accessories ① Mirror — helps to look around corners and see the unreachable areas. ② Magnet — picks up small metal objects, such as dropped rings or screws. Accessory Assembly 8.5 mm Imager Head The three accessories, including the Magnet, Hook, and Mirror, can be attached to the Imager Head in the same manner described below: Hold the accessory and the imager head.
  • Page 145: Technical Specifications

    5.5 mm Imager Head The two accessories, the Magnet and Mirror, can be attached to the Imager Head in the same manner described below: Hold the accessory and the imager head. Screw the thread part of the accessory over the imager head to fix the accessory. Technical Specifications Table 19-1 Technical Specifications Item...
  • Page 146: Operations

    Item Description  0.3 kg for 8.5 mm diameter imager head Weight  0.2 kg for 5.5 mm diameter imager head Operations Before opening the Digital Inspection application, the imager head cable must be connected to the tablet using the USB cable. Install the correct imager head accessories according to the specific needs.
  • Page 147 recording. Tap the red ring on the operating screen to start recording. Tap the red circle again to stop recording. The recorded video is automatically saved. Tap the gallery icon at the bottom-right corner to review all recorded videos. Select the corresponding button on the upper-right corner to search or delete a video.
  • Page 148: Maintenance And Service

    Maintenance and Service Maintenance Instructions Follow these guidelines to maintain your tool and ensure its optimum performance.  Use a soft cloth and alcohol or a mild window cleaner to clean the touch screen of the tablet.  Do not use any abrasive cleansers, detergent, or automotive chemicals to the tablet. ...
  • Page 149: About Battery Usage

    Your device may have not been connected to the charger properly. Check the connector. NOTE If your problems persist, please contact Autel’s technical support personnel or your local selling agent. About Battery Usage Your tablet is powered by a built-in Lithium-ion Polymer battery. This means that, unlike other forms of battery technology, you can recharge your battery while some charge remains without reducing your tablet’s autonomy due to the “battery memory effect”...
  • Page 150: Service Procedures

    Technical Support If you have any question or problem on the operation of the product, please contact us (see the following contact info) or your local distributor. AUTEL NORTH AMERICA  Phone:1-855-AUTEL-US(288-3587) Monday-Friday 9am-6pm EST  Website: www.autel.com  Email: sales@autel.com;...
  • Page 151 Dubai, U.A.E Repair Service If it becomes necessary to return your device for repair, please contact us first and then download the repair service form from www.autel.com, and fill it in. The following information must be included:  Contact name ...
  • Page 152: Compliance Information

    Compliance Information FCC Compliance FCC ID: WQ8MX808TS-17 This device complies with Part 15 of the FCC rules and Industry Canada’s license- exempt RSSs. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 153: Sar

    Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The radiated output power of this device is below the FCC radio frequency exposure limits. Nevertheless, the device should be used in such a manner that the potential for human contact is minimized during normal operation.
  • Page 154: Warranty

    Warranty Limited One Year Warranty Autel Intelligent Technology Corp., Ltd. (the Company) warrants to the original retail purchaser of this MaxiCheck Diagnostics Device that should this product or any part thereof during normal usage and under normal conditions be proven defective in material...

Table of Contents
