ADDENDUM

TO INSTRUCTION MANUAL
This addendum supplements instructions found in instruction manual XX028-06-00 for the Surveyor4 Series of
Miniature Fixed-Position Camera Domes. It pertains exclusively to Model S4VF-DN (product code 8328-04/
8328-03).
This addendum lists exceptions to instructions manual XX028-06-00 for correct installation of the S4VF-DN.
The unit does not require an isolated power supply (page 5). The camera/lens is one unit and the camera
includes an isolated power supply.
The camera mounting bracket is attached to the pan bracket. To adjust tilt, loosen the nut on the side of
the pan bracket and move to desired position (page 7).
The unit is delivered with a cable assembly connected to the interface PC board, one for power and one
for video (page 4-5).
There is a potentiometer (VR1 on the back board of the camera) for phase adjustment for line lock. It is
not on the enclosure (page 8).
There is a potentiometer (VR1 on the front board of the camera) for ALC adjustment (page 9).
There is a DIP switch on the front camera board that allows the selection of: Switch 1 - ALC (OFF) or
ELC (ON); Switch 2 – Internal (Crystal) Synchronization (OFF) or Line Lock (ON); Switch 3 – AGC (ON or
OFF); Switch 4 – BLC (ON or OFF) (page 8-9).
Specifications (page 15):
Input Voltage: 24 VAC ±20%, isolated.
Camera/Lens Specifications (page 17):
Image Device: 1/4" ExView™ CCD, 2:1 interlace, NTSC; color.
Resolution: Color: 480 TV lines; Mono: 580 TV lines.
Sensitivity: Day: 0.07 fc (0.8 lux); Night: 0.009 fc (0.1 lux) @40 IRE, f/1.4.
Synchronization: Internal/Line Lock, DIP switch selectable.
Electronic Iris: 1/60 – 1/100,000.
BLC: ON/OFF, DIP switch selectable.
ALC: ON/OFF, DIP switch selectable.
Signal-to-Noise Ratio: >48 dB (AGC off).
Copyright © 2003 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
Vicon part number 8009-5028-01-00 Section 1 Rev 1003
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TELE: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
S4 Series Fixed-Position Camera Domes
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: +44 (0) 1489 566300
NOTES
Refer to
AA028-01-00 1003
XX028-05-00
WEB: www.vicon-cctv.com
NO.
REV.
SEC.
1
