1 Description

Introduction

This document describes the integration of Modbus RTU installations into KNX systems using the Intesis KNX–
Modbus Master gateway.
The aim of this integration is to make accessible Modbus system signals and resources from a KNX control system
or device, as if it was a part of the own KNX TP-1 (EIB) system and vice-versa.
For this, Intesis acts as a Modbus RTU master device in its Modbus interface, reading/writing registers of the Modbus
slave device(s), and offering these values through its KNX interface, acting in the KNX system as another KNX device
of the system. The readings of the Modbus slave device(s) are performed by Intesis gateway automatically through
a continuous polling.
Configuration is carried out through ETS configuration tool.
This document assumes that the user is familiar with KNX and Modbus technologies and their technical terms.
