KNX – Modbus Master
TM
Intesis
Set-up procedure
1. Install Intesis in the desired installation site. Installation can be on a stable not vibrating surface.
2. Connect the KNX communication cable coming from the KNX network to the port marked as KNX Port on Intesis
(More details in section 4).
3. Connect the communication cable coming from the EIA485 port of the Modbus RTU installation to the port
marked as Port A of Intesis (More details in section 4).
4. Open ETS, open a project and add product from ETS catalog.
5. Modify the configuration as desired, and then download to the device.
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
User Manual r1.0 eng
URL
https://www.intesis.com
18 / 19
