MANUAL / ELECTRIC LONG TERM CARE BED
Technical Assistance and Parts
1 800 428-5025 (Service in English in Canada)
1 800 361-2040 (Service in French in Canada)
1 800 327-0770 (In the United States)
E-Mail (Canada):
service@bertec.strykercorp.com
Manufactured by Stryker Bertec Medical Inc
OPERATIONS MANUAL
The SUNFLOWER
Product Number: FL18M1
FL18M2
FL18E1
FL18E2
TM
February 2001
Printed in Canada
72-0400 R1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Stryker BERTEC SUNFLOWER FL18M1
Summary of Contents for Stryker BERTEC SUNFLOWER FL18M1
- Page 1 Technical Assistance and Parts 1 800 428-5025 (Service in English in Canada) 1 800 361-2040 (Service in French in Canada) 1 800 327-0770 (In the United States) E-Mail (Canada): service@bertec.strykercorp.com February 2001 Manufactured by Stryker Bertec Medical Inc 72-0400 R1.0 Printed in Canada...
-
Page 3: Table Of Contents
Operating the Emergency Crank ...................15 Storage..........................15 Stryker Bertec Medical Inc gives special attention to the quality of the information found in this document. Any comments on its content will be most welcomed. Please forward your remarks to the Technical Service department (see section 1.2). -
Page 4: Introduction
120 V, 50/60 Hz, 5 A requirements meet the CSA standard C22.2 No. 125 and UL 544 specifications for class * Stryker Bertec Medical Inc provides special attention to product improvement and reserves the right to change specifications without notice. 1.2 TECHNICAL SUPPORT... -
Page 5: Warning / Caution / Note Definitions
Introduction Chapter 1 1.3 WARNING / CAUTION / NOTE DEFINITIONS The words carry special meanings and should be carefully WARNING CAUTION NOTE reviewed. The personal safety of the patient or user may be involved. Disregarding this information could result in injury to the patient or user. These instructions point out special procedures or precautions that must be followed to avoid damaging the equipment. - Page 6 Chapter 1: The Sunflower Operations Manual • Siderails, with or without their padded covers or nets, are not intended to serve as restraint devices to keep patient from exiting the bed. Siderails are designed to keep a patient from inadvertently rolling off the bed. It is the responsibility of the attending medical personnel to determine the degree of restraint necessary to ensure a patient will remain safely in bed.
-
Page 7: Warranty
(see section 1.2) or your local representative. To Obtain Service and/or Parts For an on-site diagnosis and/or repair of a bed malfunction by a Stryker Field Service Representative or to order replacement parts (refer to section 1.6.2, "To Order Replacement Parts"... -
Page 8: Cleaning Beds
Chapter 1: The Sunflower Operations Manual Cleaning Beds • Hand wash all surfaces of the bed with a soft cloth moistened with a solution of lukewarm water and a mild detergent. • Wipe the bed clean and dry thoroughly to avoid build up of cleaning solution. Mattress Care Failure to properly clean mattress covers or dispose of defective mattress will increase the risk of exposure to pathogenic substances which may cause injury to the patient or user. -
Page 9: Manual (Fl18M1/M2) Bed Checklist
Introduction Chapter 1 Plug the power cord into a properly grounded hospital grade wall receptacle. For both models, ensure that the On/Off switch LED goes on when the switch is turned Check (if present) the yellow bed-on-caster warning LED and the casters for proper operation by doing the following: FL18E1: Press and hold the Hi-Lo switch in the foot end control panel to lower the bed until it automatically stops. - Page 10 Chapter 1: The Sunflower Operations Manual FL18M2 Bed (Floor Lock System - Bed Normally Rests on Casters) Illustration of a fully manual bed equipped with three-quarter-length siderails. LENGTH SIDERAIL OPTIONAL HEAD BOARD RESTRAINT STRAP LOCATIONS FOOT BOARD ROLLER BUMPERS OPTIONAL BUILT IN LEG TOTAL LOCK...
-
Page 11: Bed Operation Guide
Bed Operation Guide Chapter 2 2. BED OPERATION GUIDE The bed available positions are achieved either through electric commands, such as those found in the foot end control panel and the pendant control, or hand cranks. 2.1 POSITIONING THE BED THROUGH: The Foot End Control Panel Figure 2.1 A: Main Power Switch... -
Page 12: The Removable Pendant Control
Chapter 2: The Sunflower Operations Manual The Removable Pendant Control Pendant controls with varied combinations of bed function commands give access to the bed Fowler and/or Knee Gatch and/or Hi-Lo functions. These commands will function once the power switch is turned on. They can be selectively locked out using the lockout controls described above. -
Page 13: Moving Or Stabilizing The Bed (Electric And Manual Beds)
Bed Operation Guide Chapter 2 Operating the crank handle To use the crank handle: 1. Extend the appropriate crank handle from tucked away position. 2. Turn the crank handle clockwise (to raise) or counter clockwise (to lower) as needed. 3. Place the crank handle back to its tucked away position by simply pushing the top part of the handle with the thumb (where it says to push) while directing it under the bed. -
Page 14: Floor Lock System (Fl18E2 And Fl18M2 Bed Models)
Chapter 2: The Sunflower Operations Manual Floor Lock System (FL18E2 and FL18M2 Bed Models) These bed models are usually mobile because they normally rest on their casters and are stabilized by either engaging the caster locking mechanisms or lowering the bed on its legs. Stabilizing the Electric (FL18E2) and Manual (FL18M2) Beds •... -
Page 15: Head And Foot Boards
Bed Operation Guide Chapter 2 2.4 HEAD AND FOOT BOARDS Removing Boards Seize both ends of the board and lift it up until the posts come out of their sockets. Replacing Boards Head board: Insert board with posts facing toward the outer side of the bed. Foot board: Insert board with posts facing toward the inner side of the bed.
