Johnson Controls LC-200 Installation Instructions page 2

3. CONNECTION AND SETUP
Dip PULSE --> off = 1 pulse - on = 2 pulses
Dip RANGE --> off = 7m - on = 15m range
Dip LED --> off = led off - on = led on
Jumpers T - A - EOL open = NC contacts without resistors (not for UL/ULC applications)
Jumpers T - A - EOL closed = DEOL supervision with internal resistors
SUPPLY: power supply 9-15 VDC / 25 mA. Note: For UL/ULC installations the detector shall be provided with minimum of 4 hours of standby power from either
a listed compatible control unit or power supply. Use only resistive loads on the outputs.
DEOL supervision
(internal resistors/closed jumpers)
LC-200/BLC-200
All 3 jumpers closed
SUPPLY ALARM TAMPER
–
+ EOL EOL
R1
COM
LC-200: R1 = 5.6 kohm; R2 = 5.6 kohm
BLC-200: R1 = 5.0 kohm; R2 = 5.0 kohm
–
+ Zx COM TAMPER
tamper
Negative connected
Panel
Technical Characteristics
RANGE
HORIZONTAL COVERAGE
LENSES
LED
ALARM DURATION
SELF-DIAGNOSTICS
LED WALK TEST
MICROWAVE FREQUENCY
SOLID STATE RELAY
EOL RESISTANCE
CREEP ZONE DEVICE
CASE TAMPER
BACK TAMPER
ANTI-MASKING
PULSE COUNTER
RFI PROTECTION
HEAT COMPENSATION
FULLY DIGITAL
SWIVEL OPTION
POWER SUPPLY
COVER MATERIAL
PET IMMUNITY
OPERATING TEMPERATURE
HUMIDITY
DIMENSIONS
LC-200/BLC-200 complies with requirements EN 50131-2-2 Grade 2, EN 50131-2-2 Class II
Installation must be carried out by trained personnel according to professional standards.
The manufacturer accepts no responsibility if the product is tampered with by unauthorized persons.
The alarm system should be checked for proper operation at least once a month. However, a reliable electronic alarm system does not prevent
intrusion, robbery, fire or anything else but merely decreases the risk of such situations occurring.
ISTISJCEBLC200 0.0
LC-200: DEOL supervision
(external resistors/
open jumpers)
LC-200
All 3 jumpers open
SUPPLY
Zone ok = R1
–
Zone in alarm = R1 + R2
Tamper zones = open or short circuit
NC / NO TAMPER
R2
–
Negative connected
15 m
100°
LODIFF Fresnel Lens
®
POLY IR 4 material
®
blue
2 s
-
YES
-
YES
YES
YES
YES
YES
-
YES
30 V/m
YES
YES
YES
9-15 VDC / 25 mA
ABS
YES
-10°C to +40°C
UL/ULC tested: 0°C to 49°C
93% RH
114 x 63 x 40 mm
LC-200/BLC-200
BLC-200: DEOL supervision
(external resistors/
open jumpers)
BLC-200
All 3 jumpers open
ALARM TAMPER SUPPLY
+ EOL EOL –
TOP VIEW:
15m
(50ft)
TOP VIEW:
+ Zx COM TAMPER –
tamper
Negative connected
15m
(50ft)
Panel
10m
(33ft)
10m
10m
(33ft)
(33ft)
5m
(16ft)
5m 0
5m
(16ft) (16ft)
5m
0
0 (16ft)
5m
5m
(16ft)
(16ft)
10m
(33ft)
10m
10m
(33ft)
(33ft)
15m
(50ft)
SIDE VIEW:
SIDE VIEW:
2.1m
15m
2.1m
(6.8ft)
(50ft)
(6.8ft)
SIDE VIEW:
2.1m
(6.8ft)
fresnel technologies inc.
2.1m
(6.8ft)
fresnel technologies inc.
2003
2
NC (no EOL supervision/
open jumpers)
Not used on UL/ULC
listed installations
PET IMMUNE ARRA
LC-200/BLC-200
All 3 jumpers open
SUPPLY
ALARM TAMPER
PET IMMUNE ARRAY
–
+ EOL EOL
–
+ COM Zx TAMPER
tamper
Negative connected
Panel
2.1m 4.8m 8.6m
2.1m 4.8m 8.6m
(6.8ft) (15.7ft) (28.2ft)
(6.8ft) (15.7ft) (28.2ft)
101W. MORNINGSIDE DR. FORT WORTH, TX 7
2003
4.8m 8.6m
(15.7ft) (28.2ft)
101W. MORNINGSIDE DR. FORT WORTH, TX 76110, U
Installation Instructions
WP 0.9 GI 6 T1
ALARM TAMPER
+ EOL EOL
WP 0.9 GI 6 T1
35.6mm
(1.4 in)
+ Zx COM TAMPER
35.6mm
tamper (1.4 in)
Panel
95°
95°
15m
15m
(50ft)
(50ft)
15m
(50ft)
