_________________________________________________________________________________________ DS3106DK
DESIGNATION
R5, R11, R13, R15,
R21–R24, R29–R32,
R65–R68
R6
R7, R9, R10, R12,
R14, R84, R110,
R113, R115, R116,
R120–R123
R8, R16, R18, R46,
R64, R83, R100,
R101, R102
R28
R35–R40, R42, R44,
R94, R108
R97
SW1
SW5
TP1–TP22,
TP49–TP60,
TP65–TP84
U1, U2, U5, U13,
U14, U23, U24, U28
U3
U4, U6
U7, U25
U8
U26
U29
U35
U41
U42
U44
U45
U46
QTY
16 L_RES 0603 51.1 Ohm 1/16W 1%
1 RES 0603 100K Ohm 1/16W 5%
14 L_RES 0603 10K Ohm 1/16W 5%
9 RES 0603 DO NOT POPULATE
1 RES 0603 33.2 Ohm 1/16W 1%
10 L_RES 0603 330 Ohm 1/16W 5%
1 RES 0603 20K Ohm 1/16W 5%
1 SWITCH DPDT SLIDE 6PIN TH
1 SWITCH MOM 4PIN SINGLE POLE
54 Test Points, 1 PLATED HOLE, DO NOT STUFF
L_TINYLOGIC HIGH SPEED 2-INPUT OR GATE,
8
5 PIN SOT23
IC, LINE CARD TIMING, -40°C to +85°C, 64 PIN
1
QFP
2 LINEAR REGULATOR, 3.3V, 16 PIN TSSOP-EP
L_TINYLOGIC HIGH SPEED 2-INPUT XOR
2
GATE, 5 PIN SOT23
1 LINEAR REGULATOR, 1.8V, 16 PIN TSSOP-EP
IC, LINEAR REGULATOR, 1.5W, 2.5V OR ADJ,
1
1A, 16 PIN TSSOP-EP
IC, TCXO, 12.8MHz, 0°C to +70°C, 16-PIN SOIC,
1
DO NOT POPULATE
IC, LINE CARD TIMING WITH SYNCHRONOUS
1 ETHERNET SUPPORT, -40 TO 85C, 81 PIN BGA,
DO NOT POPULATE
DUAL RS232 XMITR/RCVR 16 PIN SOIC (300
1
MIL)
1 HIGH SPEED MICRO 44-PIN TQFP 0°C to +70°C
MICROPROCESSOR VOLTAGE MONITOR,
1
3.08V RESET, 4PIN SOT143
MICROPROCESSOR VOLTAGE MONITOR,
1
4.38V RESET, 4PIN SOT143
IC, SINGLE-CHIP USB TO UART BRIDGE, 28 PIN
1
QFN
DESCRIPTION SUPPLIER PART
PAN ERJ-3EKF51R1V
PAN ERJ-3GEYJ104V
PAN ERJ-3GEYJ103V
NA NA
PAN ERJ-3EKF33R2V
PAN ERJ-3GEYJ331V
PAN ERJ-3GEYJ203V
TYC SSA22
PAN EVQPAE04M
NA NA
FAI NC7SZ32M5
DAL DS3106
MAX MAX1793EUE-33
FAI NC7SZ86M5
MAX MAX1793EUE-18
MAX MAX1793EUE-25
DAL DS4026+BCC
DAL NOT POPULATED
DAL DS232AS
DAL DS87C520-ECL
MAX MAX811TEUS-T
MAX MAX812MEUS-T
SIL CP2101
