_________________________________________________________________________________________ DS3106DK
5.

Appendix 1: Hardware Components

DESIGNATION
C1, C2, C5, C6,
C9–C12, C15, C42,
C59–C138, C140,
C142, C143, C145,
C147, C151, C155,
C163–C166, C168,
C169
C3, C13 ,C14, C16,
C41
C4, C17, C18, C20
C7
C8
C19
C34–C38, C51–C58,
C139, C141, C153,
C154
C39, C40
C43
D1
D2, D7
DS1–DS4, DS6
DS5, DS10
DS16
J1, J6, J7, J22, J27,
J40, J41
J3
J13
J14
J19
J50
J51
J54
JMP1–JMP6,
JMP9–JMP12,
JMP16
JMP7, JMP8,
JMP36, JMP37
JMP13, JMP14,
JMP15
JMP62, JMP63
R1–R4, R17, R19,
R20, R25–R27, R33,
R34, R41, R43, R45,
R47–R63, R111,
R112, R117, R118
QTY
0.1µF ±20% 16V X7R ceramic capacitors (0603)
103
4.7µF ±10%, 25V X5R ceramic capacitors (1206)
5
6.8µF ±10%, 6.3V X5R ceramic capacitors (1206)
4
68µF ±20%, 16V tantalum capacitor (D case)
1
0.01µF ±10%, 50V X7R ceramic capacitor (0603)
1
100µF ±20%, 4V ceramic capacitor (1206)
1
10µF ±20%, 10V ceramic capacitors (1206)
17
22pF ±10%, 100V ceramic capacitors (1206)
2
1µF ±10%, 16V ceramic capacitor (1206)
1
1 DIODE 1A 50V GEN PURPOSE SILICON
2 SCHOTTKY DIODE, 1 AMP 40 VOLT
5 SMD green LEDs
2 SMD red LEDs
1 SMD green LED
7 CONNECTOR, SMB, 50 OHM VERTICAL, 5PIN
CONN 2.1MM/5.5MM PWRJACK RT ANGLE PCB,
1
closed frame, high current 24VDC@5A
1 SOCKET, BANANA PLUG, HORIZONTAL, RED
CONNECTOR, SMB, 50 OHM VERTICAL, 5PIN,
1
DO NOT POPULATE
1 SOCKET, BANANA PLUG, HORIZONTAL, BLACK
1 CONN, DB9 RA, LONG CASE
1 TERMINAL STRIP, 10 PIN, DUAL ROW, VERT
1 CONN, USB, TYPE B SINGLE RT ANGLE, BLACK
11 L_HEADER, 3-PIN, .100 CENTERS, VERTICAL
4 L_2 PIN HEADER, .100 CENTERS, VERTICAL
3 DO NOT PLACE, SHORTED 2PIN TH JUMPER
2 L_3 PIN HEADER, .100 CENTERS, VERTICAL
36 L_RES 0603 0 Ohm 1/16W 1%
DESCRIPTION SUPPLIER PART
AVX 0603YC104MAT
PAN ECJ-3YB1E475K
PAN ECJ-3YB0J685K
PAN ECS-T1CD686R
AVX 06035C103KAT
TAI AMK316BJ107ML-T
PAN ECJ-3YB1A106M
AVX 12061A220KAT2A
PAN ECJ-3YB1C105K
GEN 1N4001
IRF 10BQ040
PAN LN1351C
PAN LN1251C
PAN LN1351C
AMP 413990-1
CUI, INC PJ-002AH
MSR 164-6219
AMP 413990-1
MSR 164-6218
AMP 747459-1
NA NA
MOL 67068-0000
STC TSW-103-07-T-S
STC TSW-102-07-T-S
NA NA
STC TSW-103-07-T-S
AVX CJ10-000F
17
