TTI QL II Series Service Manual page 15

PCB ASSEMBLY – SM POWER – QL355 and QL564 continued/...
Part No. Description
23105-4220 RES SM0805 220KF W1
23105-5100 RES SM0805 1M00F W1
23407-0100 CAP SM0805 10PG CER NPO
23407-0101 CAP SM0805 100PG CER NPO
23461-0020 CAP SM0805 100NZ 50V CER Y5V
23461-0040 CAP SM0805 1N0K 50V CER X7R
23559-3471 CAP SM 470U 16V AL ELEC
23559-5100 CAP SM 10U 35V AL ELEC
23559-5220 CAP SM 22U 35V AL ELEC
23559-6010 CAP SM 1U 50V AL ELEC
25021-1010 DIO SM BAS21 200V/200mA SOT23
25340-1000 TRAN SM PNP BC859C SOT23
25340-1010 TRAN SM PNP PMBT3906
25377-1000 TRAN SM NPN BC849C SOT23
25381-1000 TRAN SM NPN SMBT3904
25381-1010 TRAN SM NPN BC817
27103-1040 IC SM LM393
27164-1070 IC SM ULN2003AD SOIC16
27227-0210 IC SM 4021
27227-0940 IC SM 4094
27239-0000 IC SM 74HC00
27239-0140 IC SM 74HC14
27239-5740 IC SM 74HC574
27250-2290 IC SM PIC16F887-I/PT 44TQFP
27403-0130 IC SM 24LC16B/SN SOIC8
35555-5130 PCB - POWER - nQL355/564
PCB ASSEMBLY – POWER – QL564
Part No. Description
20073-9801 SCREW No.4x1/4in. Plastite
20613-0026 SIL-PAD 900S 100MM X 25MM
20670-0366 HEATSINK LS01000 100MM PLAIN
20670-0367 CLIP 1 FOR TO220/TO247 H/S
22240-0150 RELAY 12V DPDT 8A
22312-0242 FUSE CLIPS PCB MTG
22315-0310 FUSE 10A ANTISURGE(T) HBC UL
22315-0451 FUSE 750mAT SUBMIN PCB MNT UL
14
SO16
SO14
SO14
SO20
Position
R14-15 ,R143
R10, R31, R115 ,R135
C56-57
C21-22
C15 ,C18-20, C55, C58, C59, C61, C64
C30-37 ,C47-54
C71
C6-8 ,C43
C14
C86 ,C88-90
D1-7 ,D24
Q5-9 ,Q26
Q13-14
Q1-2 ,Q10-12, Q18 ,Q24
Q17 ,Q21
Q23
IC6 ,IC50
IC38
IC34-35 ,IC41
IC28
IC8
IC7
IC32-33
IC9
IC31
Position
HEATSINKS
FOR HS1, HS2
SK1-2
FOR IC1-3,Q22,SCR1-2,BR1,Q15,Q16
RL1-2
FS1
FS1
FS4 ,FS6
