TTI QL II Series Service Manual page 29

MECHANICAL ITEMS – QL564T & QL564TP UNPACKED PARTS LIST continued/...
Part No. Description
22571-1150 TERM PSU SAFETY:REAR INS YEL
22571-1210 TERM PSU SFTY2 28L SPINDLE
GRY
22571-1220 TERM PSU SAFETY2:TOP INS RED
22571-1230 TERM PSU SAFETY2:TOP INS BLK
22571-1240 TERM PSU SAFETY2:TOP INS GREY
22575-0009 SHORTING BLOCK
22575-0077 SKT 2 WAY IDT .1P
22575-0078 SKT 3 WAY IDT .1P
22575-0202 SKT 2W .156 20AWG YELLOW IDT
22575-0205 SKT 5W .156 20AWG Yellow IDT
22575-0206 SKT 6W .156 20AWG Yellow IDT
23557--0506 CAP 10U 63V ELEC P2
28522-0050 FAN 80MM 12VDC (QL)
31512-0820 BRACKET F.PNL/CHASS QLTRIPLE
31512-0830 BRACKET R/PANEL TO PCB QL
31512-1080 BRACKET - FAN SUPPORT - QL T
33111-0280 BRACKET HANDLE - PSU
UNIVERSAL
33143-0293 FOOT - TILT - HOUSING GREY3
33143-0303 FOOT - TILT - SUPPORT - GREY3
33147-0273 FRONT MOULDING QLT PRTD GY3
UL
33331-9710 OVERLAY TERM/NAM/LOGQL564T
33331-2040 OVERLAY TERM/NAM/LOGQL564TP
33533-0430 LENS - DISPLAY - QL
33533-0440 WINDOW - DISPLAY - QL
33536-4303 COVER PAINTED QL TRIPLE
GREY3
33536-4360 CHASSIS - PRINTED QL TRIPLE
33536-4840 CHASSIS - PRINTED QL TRIPLE P
37113-2113 BUTTON 6.5D X 9.4L GREY3
37151-0533 KNOB 32MM (QL) D-SHAFT GREY3
37541-1230 LABEL SAFETY EARTH GRN/WHITE
43187-2030 WIRE SET CUT BASIC nQL UL
43187-2040 WIRE SET CUT nQL-T UL
43187-2050 WIRE SET CUT QL-P UL
28
Position
MASTER SEL3 (1), SLAVE LK1 (1), SLAVE
LK2 (1)
FAN (2) POWER TO POWER (2)
POWER to POWER
TX TO PWR PCB
TX TO PWR PCB
UL SP
FEET FRONT
FEET FRONT
FRONT PANEL
