TTI QL II Series Service Manual page 17

PCB ASSEMBLY – POWER – QL564 continued/...
Part No. Description
28500-1190 XTAL 18.432MHZ MICROPROCSR
44117-0181 PCB ASSY SM POWER nQL355
PCB ASSEMBLY – CONTROL
Part No. Description
10300-0313 PAD P/E S/AD 12 X 15MM
22240-0070 RELAY TYPE 47 (12VDC)
22455-0040 TAB 4.8MAX 0.8MM STR PCB MTG
22573-0251 HEADER 6 WAY STR .1P F/LOCK
22574-0316 SKT 16 WAY (2x8)
23105-1100 RES SM0805 100RF W1
23105-1330 RES SM0805 330RF W1
23105-2100 RES SM0805 1K00F W1
23105-2470 RES SM0805 4K70F W1
23105-3100 RES SM0805 10K0F W1
23105-3200 RES SM0805 20K0F W1
23105-3205 RES SM0805 20K5F W1
23105-3470 RES SM0805 47K0F W1
23105-4100 RES SM0805 100KF W1
23105-4220 RES SM0805 220KF W1
23105-4270 RES SM0805 270KF W1
23105-4330 RES SM0805 330KF W1
23106-2200 RES SM0805 2K00D W1 25PPM
23106-3100 RES SM0805 10K0D W1 25PPM
23106-3110 RES SM0805 11K0D W1 25PPM
23106-3130 RES SM0805 13K0D W1 25PPM
23106-3200 RES SM0805 20K0D W1 25PPM
23202-1150 RES 150RF W60 MF 50PPM
23215-2845 RES 8K45B W25 MF 15PPM
23215-3110 RES 11K0B W25 MF 15PPM
23215-3130 RES 13K0B W25 MF 15PPM
23215-4150 RES 150KB W25 MF 15PPM
23284-0110 RES 0R51J 2W5 WW
23286-0040 RES 0R05J 15W WW ALUM HSD
23385-2220 RES PS/H 2K2 CF 6MM
23427-0388 CAP 220PK 100V CER P2.5
23427-0388 CAP 220PK 100V CER P2.5
16
Position
XTL1
Position
FOR R50
RL3
FAS1, 2
PJ3
PJ18,19
R109
R44-49,122
R38, 56, 78-81, 95,106,107,114
R28,91
R29,31,32,43,52,53,72,73,118,123,124,128
R67, 68,102,105
R35
R76
R97, 98,108
R77,103,104,113,131
R66, 69
R55, 62, 94
R83, 84
R99,100,120,121
R87
R88
R39, 82, 85,101
R54,125
R63, 74
R57
R61
R64, 65
R51
R50
VR1, 2
C81
C49
