TTI QL II Series Service Manual page 23

PCB ASSEMBLY – SM AUX TERM/POWER continued/...
Part No. Description
23105-3430 RES SM0805 43K0F W1
23105-4100 RES SM0805 100KF W1
PCB ASSEMBLY – SM AUX TERM/POWER
Part No. Description
23407-0470 CAP SM0805 47PG CER NPO
23414-3226 CAP SM1210 22UK 16V CER
23461-0015 CAP SM0805 10NK 50V CER X7R
23461-0020 CAP SM0805 100NZ 50V CER Y5V
23461-0040 CAP SM0805 1N0K 50V CER X7R
23461-0050 CAP SM0805 22NJ 50V CER X7R
23461-0070 CAP SM0805 4N7J 50V CER X7R
23461-0080 CAP SM0805 47NK 50V CER X7R
23461-0200 CAP SM0805 2N2J 50V CER X7R
23461-0310 CAP SM1206 1UK 25V CER X7R
23559-5220 CAP SM 22U 35V AL ELEC
25377-1000 TRAN SM NPN BC849C
27002-0020 OPTO-COUPLR SM IL206AT SOIC8
27106-1160 IC SM LM324M OP AMP
27106-1250 IC SM MCP602 OP AMP
27168-1100 IC SM MP2307 SO8
27239-0140 IC SM 74HC14
27250-2300 IC SM PIC16F785-I/SO 20SOIC
35555-5110 PCB - AUX TERM/POWER - nQLT
MECHANICAL ITEMS - QL355 & QL355P - UNPACKED PARTS LIST
Part No. Description
10232-0360 TUBING PVC CLEAR 9.5ID UL
20620-0010 CLIP - ENCODER KNOB
20661-0290 SPACER Clr No. 4 x 22.2 Nylon
20662-0570 FOOT SELF ADHESIVE GREY
20662-9101 INSTRUMENT FOOT
22040-0030 FERRITE SLEEVE APPX 9/16/17L
22115-0870 TRANSFORMER-nQL355 ULSP
22219-0090 SWITCH ROCKER DPST GREY UL SP
22315-0316 FUSE 1.6A ANTISURGE(T)HBC UL
22520-0200 ACRECEP 10AMPFUSE SNAPI ULSP
22571-1101 WASHER ALUMINIUM SAFETY TERM
22
SOT23
SO14
SO14
Position
R19, R21
R1, R13, R33-34, R41
Position
C11, C14, C16
C1-3
C6, C15, C22
C10, C17-21, C23-25, C28-30, C33,C34
C8
C26
C7,C36
C27
C9
C32
C13
Q1
IC6-10
IC4
IC3
IC1
IC2
IC11
Position
Mains wire to mains switch sleeving (70mm)
POWER TOP
FEET FRONT
FEET BACK
QTY 1 FOR OUTPUT LEADS (2 PASSES),
QTY 1 FOR 6 SENSE WIRES (2 PASSES)
